Configuration
Code table
8
8.3

8.3-58
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0891

cfg: M-add 1000 FIXED0%  Selection list 1 Configuration of analog input
signal, function block MCTRL
z Additional torque setpoint or
torque setpoint
 8.2-48
C0892

cfg: lo-M-lim 5700 ANEG1-OUT  Selection list 1 Configuration of analog input
signal, function block MCTRL
z Lower torque limit in [%] of
C0057
C0893

cfg: hi-M-lim 19523 FCODE-472/3  Selection list 1 Configuration of analog input
signal, function block MCTRL
z Upper torque limit in [%] of
C0057
C0898

CFG: M-LIM
switch
0
0 M-LIM ON Reduced torque
limit is active
Torque limitation in the field
weakening range, function block
MCTRL
z If the torque limit is reduced,
the maximum possible torque
in the field weakening range is
lowered with 1/f. This provides
a higher motor stability in the
field weakening range
 8.2-48
1 M-LIM OFF Reduced torque
limit is inactive
C0899

cfg: n/m-swt 1000 FIXED0  Selection list 2 Configuration of digital input
signal, function block MCTRL
z LOW = active speed control
z HIGH = active torque control
 8.2-48
C0900

cfg: qsp 10250 R/L/Q-QSP  Selection list 2 Configuration of digital input
signal, function block MCTRL
z HIGH = drive performs quick
stop
 8.2-25
 8.2-48
C0901

cfg: i-set 1000 FIXED0%  Selection list 1 Configuration of analog input
signal, function block MCTRL
z Setting of integral action
component of the speed
controller
 8.2-48
C0902

cfg: i-load 1000 FIXED0  Selection list 2 Configuration of digital input
signal, function block MCTRL
z HIGH = the integral action
component at MCTRL-I-SET is
accepted by the speed
controller
C0903

cfg: BOOST 5015 MCTRL-BOOST  Selection list 1 Configuration of analog input
signal, function block MCTRL
z Boost of the motor voltage
 8.2-25
C0904

cfg: DC-BREAK 1000 FIXED0  Selection list 2 Configuration of digital input
signal, function block MCTRL
z HIGH = Motor is braked
 8.2-25
 8.2-48
C0905 DIS: DC-BREAK 0 1 Function block MCTRL
z Display of the signal linked in
C0904
