Configuration
Code table
8
8.3
8.3-19
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0195 BRK1 T act 99.9 0.0 {0.1 s} 99.9 Brake closing time, function block
BRK1
z C0195 = 99.9 s: infinite
z After the time has elapsed in
C0195, the status ”brake
applied” is reached
See System
Manual
(extension)
C0196 BRK1 T release 0.0 0.0 {0.1 s} 60.0 Brake opening time, function
block BRK1
z Opening time can be obtained
from the technical data of the
brake
z After the time has elapsed in
C0196, the status ”brake
released” is reached
C0200 S/W ID
x
y
Main version
Subversion
Software ID
z Display only
S9300MVxy000 9300 vector 0.37 ... 90 kW
S9300MVxy020 9300 vector 110 ... 400 kW
C0201 S/W Date xxx yy zzzz xxx = month
yy = day
zzzz = year
Software creation
z Display only
C0202 Internal identification
z Display only
C0203 Commission number
z Display only
C0204 Serial number
z Display only
C0206 Product date xx/yy/zz Date of production
z Display only
z xx = day, yy = month, zz = year
C0207 DL info 1 Download info 1
z Display only
C0208 DL INFO 2 Download info 2
z Display only
C0209 DL INFO 3 Download info 3
z Display only
C0220 NSET Tir add 2.00 0.00 {0.01 s} 9999.90 Acceleration time T
ir
for
additional setpoint, function
block NSET
z The acceleration time refers to
a speed variation of 0 ... C0011
See System
Manual
(extension)
C0221 NSET TIF ADD 2.00 0.00 {0.01 s} 9999.90 Deceleration time T
if
for
additional setpoint, function
block NSET
z The deceleration time refers to
a speed variation of C0011 ... 0
C0222 PCTRL Vp 1.0 0.1 {0.1 } 500.0 Gain V
p
, function block PCTRL1
See System
Manual
(extension)
C0223 PCTRL1 Tn 400 20 {1 ms} 99999 Integral action component T
n
,
function block PCTRL1
z C0223 = 99999 ms: no integral
action component
C0224 PCTRL1 Kd 0.0 0.0 {0.1 } 5.0 Differential component K
d
,
function block PCTRL1
To Next Page
