Wiring the standard device
Important notes
Protection of persons
5
5.1
5.1.1

5.1-1
EDSVF9333V EN 3.0-06/2005
5.1 Important notes
 Stop!
The drive controller contains electrostatically sensitive
components.
The personnel must be free of electrostatic charge prior to
assembly and service operations.
5.1.1 Protection of persons
 Danger!
Before working on the controller, check that no voltage is applied
to the power terminals:
ƒ Because the power terminals V, W, +U
G
and -U
G
remain live
for at least 3 minutes after disconnecting from mains.
ƒ Because the power terminals L1, L2, L3, U, V, W, +U
G
and -U
G
remain live with the motor stopped.
All pluggable terminals m ust only be connected or disconnected when no
voltage is applied!
Pluggable terminal strip

Lenze EVF9325 Specifications

General

Output Current	25 A
Protection Class	IP20
Output Power	11 kW
Control Mode	Sensorless vector control
Input Voltage	380-480V AC
Control Method	vector control
Communication Interfaces	RS485, CANopen
Output Voltage	0-480V AC
Power	11.0 kW
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
