4�6�2� TEST STATUS
This status is identied by the symbol in the unit status area of the display (Figure 12).
The stages can be connected and disconnected manually, and the measured parameters that
relate to each one of the stages can be displayed. It also comprises the AutoTest function,
which scans and calculates all the stages of the unit.
A very long press (> 10s) of the key in any of the measurement screens causes the
unit to enter the Test status.
A very long press (> 10s) of the key in any of the test screens causes the unit to return
to the Measurement status.
Use keys and to browse the various screens.
If 5 minutes pass without any keys being pressed, the unit returns to the main screen.
Disconnection screen Parameters
Transition screen: used for the unit to
disconnect all the stages automatically before
entering Test status.
While in this screen, the unit does not
respond to the keys.
The unit automatically exits this screen, and
this can take a certain amount of time.
AutoTest Parameters
AutoTest home screen.
To start the AutoTest:
Press the key, OFF blinks.
Press the key to switch from OFF to START
Press the key to start the AutoTest
54
