4�9�3� MODBUS MEMORY MAP
A.- Measurement Variables
For these variables Function 04 is implemented: reading logs.
The Modbus addresses of all the tables are hexadecimal.
Table 12: Modbus memory map: measurement variables (Table 1)
Parameter Instantaneous Maximum Minimum Units
L1 Phase voltage 00-01 200-201 300-301 V/100
L1 Current 02-03 202-203 302-303 mA
L1 Active power 04-05 204-205 304-305 W
L1 Inductive Reactive Power 06-07 206-207 306-307 varL
L1 Capacitive Reactive Power 08-09 208-209 308-309 varC
L1 Reactive power 0A-0B 20A-20B 30A-30B var
L1 Apparent power 0C-0D 20C-20D 30C-30D VA
L1 Reactive Power Consumed 0E-0F 20E-20F 30E-30F var
L1 Reactive Power Generated 10-11 210-211 310-311 var
L1 Power Factor
(1)
12-13 212-213 312-313 -
L1 Cos φ
(1)
14-15 214-215 314-315 -
L1 kW sign
(1)
16-17 - - +1 or -1
L1 kvar sign
(1)
18-19 - - +1 or -1
L2 Phase voltage 1A-1B 21A-21B 31A-31B V/100
L2 Current 1C-1D 21C-21D 31C-31D mA
L2 Active power 1E-1F 21E-21F 31E-31F W
L2 Inductive Reactive Power 20-21 220-221 320-321 varL
L2 Capacitive Reactive Power 22-23 222-223 322-323 varC
L2 Reactive Power 24-25 224-225 324-325 var
L2 Apparent Power 26-27 226-227 326-327 VA
L2 Reactive Power Consumed 28-29 228-229 328-329 var
L2 Reactive Power Generated 2A-2B 22A-22B 32A-32B var
L2 Power Factor
(1)
2C-2D 22C-22D 32C-32D -
L2 Cos φ
(1)
2E-2F 22E-22F 32E-32F -
L2 kW sign
(1)
30-31 - - +1 or -1
L2 kvar sign
(1)
32-33 - - +1 or -1
L3 Phase voltage 34-35 234-235 334-335 V/100
L3 Current 36-37 236-237 336-337 mA
L3 Active Power 38-39 238-239 338-339 W
L3 Inductive Reactive Power 3A-3B 23A-23B 33A-33B varL
L3 Capacitive Reactive Power 3C-3D 23C-23D 33C-33D varC
L3 Reactive Power 3E-3F 23E-23F 33E-33F var
L3 Apparent Power 40-41 240-241 340-341 VA
L3 Reactive Power Consumed 42-43 242-243 342-343 var
L3 Reactive Power Generated 44-45 244-245 344-345 var
L3 Power Factor
(1)
46-47 246-247 346-347 -
L3 Cos φ
(1)
48-49 248-249 348-349 -
L3 kW sign
(1)
4A-4B - - +1 or -1
L3 kvar sign
(1)
4C-4D - - +1 or -1
60
Controller MASTER control VAR FAST
Instruction Manual
