Manitowoc 14000 Service And Maintenance Manual

Reference Only
UNDER CARRIAGE 14000 SERVICE MANUAL
8-4
Published 09-10-14, Control # 065-24
Item Description Item Description
1 Bolt and Nut 7 Tread
2 Cover 8 Crawler Roller
3 Jack Cylinder 9 Intermediate Roller
4 Support 10 Hand Pump
5 Rod 11 Center Punch A
6a Shim - 0.134 in (3,4 mm) 12 Center Punch Line B
6b Shim - 0.250 in (6,4 mm)
4
6
1
8
9
2 753
11
10
12
FIGURE 8-2
14CSM8-2
Straight
Edge
Crawler
Tumbler
Gap
1 in (25 mm) Tight Limit
2-1/2 in (64 mm) Loose Limit
Both Side of
Crawler
See page 8-7
