Luggage nets
G
Risk of injury
Only place lightweight objectsinthe luggage
net. Do not use it to transport heavy, sharp-
edged or fragile objects. The luggage net can-
not secure the objects sufficiently in the event
of an accident.
Luggage nets are located in the front-
passenger footwell and on the back of the
driver's and the front-passenger seat.
Removable front-passenger seat
Removing the front-passenger seat
!
To avoid damage, the head restraint must
be pushed in fully before the front-
passenger seat is removed.
!
Do not operate the lever until you have
pulled out the connector. Operating the
lever will otherwise cause damage to
mechanical and electronic components.
X
Move the front-passenger seat to its rear-
most position.
X
Disconnect connector :.
Asignal sounds. The lock for lever ; is
released.Ifthe engine is running, the
4 PASSENGER AIRBAG OFF indicator
lamp flashes and the + warning lamp
lights up after a short time.
X
Move the front-passenger seat to its centre
position.
It is only possible to remove the seat with-
out tilting it when it is in this position.
X
Place connector : under the seat in such
a way that the hose does not get caught on
the seat frame.
X
Swing lever ; forwards and pull upwards.
The seat slides out of the front mounting
cups.
X
Take hold of the seat at the back of the
backrest and at the front edge of the seat
cushion.
X
Guide the seat through the front-passenger
door opening.
X
Open cable box = and place connec-
tor : inside.
X
Close cable box =.
G
Risk of injury
The front-passenger seat which has been
removed contains an active sidebag. Do not
attach a power source to the connector on the
seat, otherwise the airbag could inflate. Store
the seat out of the reach of children.
Stowage areas
191
Stowing and features
