Fitting the front-passenger seat
G
Risk of injury
The mounting cups must be free from dirt and
other items in order for the front-passenger
seat to engage securely.
You must connect up the connector, so that
the front-passenger airbag can deploy in the
event of an accident.
If it is not connected and the engine is run-
ning, the 4 PASSENGER AIRBAG OFF
warning lamp flashes and the + warning
lamp lights up after a short time.
:
Rear mounting cups
;
Front mounting cups
=
Connector
?
Cable box
A
Lever
B
Seat frame
X
Takeconnector = out of cable box ? and
place it at the front.
X
Take hold of the seat at the back of the
backrest and at the front edge of the seat
cushion.
X
Guide the seat through the front-passenger
door opening.
X
Move the seat into position over the mount-
ing cups.
X
Insert the seat hook into rear mounting
cups :.
X
Push the front of the seat down until it
engages.
Lever A springs back to its starting posi-
tion. Only then is the seat correctly locked
in position.
X
Route connector = over seat frame B.
X
Insert connector = into the coupling on
the seat.
G
Risk of injury
Before starting off, make sure that the seat
has engaged properly.
Folding backrest on the front-
passenger seat
X
To fold forward: press the backrest back
slightly.
X
Pull release handle : and fold the back-
rest fully onto the seat cushion until it
engages.
X
To fold back: push the backrest down
slightly and pull release handle :.
X
Fold the seat backrest back until it
engages.
