X
Fold both plates upwards :.
X
Fold outlower plate ;.
X
Guide the lugs on the lower plate fully into
the openings in base plate =.
X
On level ground: place chocks or other
suitable items under the front and rear of
the wheel that is diagonally opposite the
wheel you wish to change.
X
On downhill gradients: place chocks or
other suitable items in front of the wheels
of the front and rear axle.
Raising the vehicle
G
Risk of injury
The jack is intended only for lifting the vehicle
briefly for wheel changes.
The vehicle must be placed on stands if you
intend to work under it.
Make sure that the jack is placed on a firm,
non-slip, level surface. Do not use wooden
blocks or similar objects as a jack underlay.
The vehicle could otherwise slip off the jack
and seriously injure you.
Do not start the engine at any time while the
wheel is being changed.
Do not lie under the vehicle when it is being
supported by the jack.Ifyou do not raise the
vehicle as described, it could slip off the jack
(e.g. if the engine is started or a door or the
tailgate is opened or closed) and seriously
injure you.
G
Risk of accident
If you fail to position the jack correctly, the
vehicle may:
R
slip off the jack
R
injure you or others
R
be damaged.
Therefore, make sure that the jack is posi-
tioned correctly in the respective jacking
points. Before positioning the jack, remove
any dirt that may have collected in the jacking
points. Please note that you must position the
jack in the opening of the jacking point.
Steel wheel with wheel trim
X
Vehicles with steel wheels: carefully
reach into two of the wheel trim openings
and remove the wheel trim.
X
Using wheel wrench :, loosen the bolts on
the wheel you wish to change by about one
full turn. Do not unscrew the bolts com-
pletely.
The jacking points for the jack are located
behind the wheel housings of the front wheels
and in front of the wheel housings of the rear
wheels.
X
Take the socket wrench and ratchet ring
spanner out of the vehicle tool kit.
X
Insert the socket wrench into the ratchet
ring spanner and place it on the jack so that
the letters AUF are visible.
228
Flat tyre
Breakdown assistance
