Stowage well underneaththe luggage
compartment floor
Important safety notes
G
Risk of injury
You should always close the luggage com-
partment floor if you are transporting objects
in the stowage well underthe luggage com-
partment floor.
Otherwise, you and other vehicle occupants
could be injured by objectsbeing thrown
around the vehicle in the event of sharp brak-
ing, a sudden change in direction or an acci-
dent.
!
The maximum load capacity of the stow-
age well under the luggage compartment
floor is 25 kg.
Removing/fitting the luggage compart-
ment floor (3-door vehicles without var-
iable luggage compartment floor)
You can remove the luggage compartment
floor to enable you to load and unload the
stowage well more easily.
X
To remove: raise the luggage compart-
ment floor to an angle of approximately
45Ëš.
X
Remove the luggage compartment floor.
X
To fit: insert the luggage compartment
floor into the guide rail at an angle of
approximately 45Ëš.
X
Fold the luggage compartment floor down.
Opening/closing the luggage compart-
ment floor (vehicles with variable lug-
gage compartment floor)
X
To open: pull handle : until it is vertical
and then swing luggage compartment
floor ; upwards.
X
Press bag hook =(Y page 199).
Bag hook = slides out.
X
Place luggage compartment floor ; onto
bag holder =.
X
To close: press in bag holder = until it
engages.
X
Swing the luggage compartment floor
downwards.
Setting the height of the luggage com-
partment floor
The stowage well under the luggage compart-
ment floor can be increased or decreased in
size as necessary. To do this, you can lock the
floor at two differentheights. The upper catch
Stowage areas
201
Stowing and features
