Mindray DP-50 User Manual

3-10 System Preparation
3.11 Basic Screen and Operation
3.11.1 Basic Screen
The following diagram maps out the different areas in the screen:
Logo
Hospital name
Patient Information
Accession#
Freeze
icon
Operator Exam time
Probe
Acoustic power, MI/TI
Menu area Image area
Product Mode
Exam Mode
Image Parameters
Thumbnail
preview&
zoom
window
Cine Review Area
Bodymark & Comment
Thumbnail Area of Images Saved
Help information area
System status icon
 Information Area
The information area displays manufacturer logo, hospital name, exam date & time,
acoustic power & MI/TI, freeze icon, patient information, probe model, current exam mode,
and accession #, etc. It can be preset whether to display the operator, patient gender, age,
ID, name etc. via [Setup]-> [System Preset]-> [General]. See “11.1.2 General” for detailed
preset procedures.
 Manufacturer logo
Manufacturer logo, displayed in the upper left corner of the screen.
 Hospital name
Displays the hospital name. Hospital name can be set via [Setup]-> [System Preset]-
> [Region].
 Exam time
Displays the exam time, including date and time. Exam time can be set via [Setup]->
[System Preset]-> [Region]. Exam time will be frozen with the frozen image.
 Acoustic power & MI/TI
Displays the acoustic power. Including the acoustic power, MI (Mechanical Index)
and TI (Thermal Index).
