System Preparation 3-13
 None-fixing Area
Position of areas illustrated here are not fixed, you can move them by the trackball within
a certain area on the display.
 Result window
The measurement result window displays the results of recently performed
measurements.
To move the result window:
a) Place the cursor on the title of result window (you can see the cursor changes
into
).
b) Press <Set> and move the trackball, the window moves together with the cursor.
c) Move the cursor to the target position, press [Set] again to anchor the result
window in the target position.
 Comment area
For details, please refer to “8 Comments and Body Marks”.
 Body mark area
For details, please refer to “8 Comments and Body Marks”.
3.11.2 Basic Operations of Screens
A screen consists of title, page tabs, contents and buttons, as shown in the following figure:
Composition
Description
Title Bar
The title bar is used to give a description for the content and
function of the screen.
Page Tab
For some screens, contents are distributed across several
pages. Use the selection pointer and <Set> key to
open/close the available pages. Use the selection pointer
and [Set] key to open / close the available pages.
Title
Ta b
Control
button
Contents
