5-24 Image Optimization
Operations
Press <Set> to hide or show between the M-mark lines and press <Cursor> to
show the cursor.
The activated M-mark line will be green.
Adjustment of the M-mark Line
Description
To adjust the position and angle of the M-mark line.
Operations
 Position Adjustment
When the M-mark line is activated, move the trackball left and right to adjust
the position. The direction is recognized by the arrow at the end of the line.
 Angle Adjustment
When the M-mark line is activated, move the trackball to adjust the fulcrum of
the line, and adjust through the [Angle] item on the menu.
The adjusting angle range is 0-360, in increments of 1.
5.9.1.2 Exit Free Xros M
In Free Xros M mode, click [Free Xros M] or press <B> or the user-defined Free Xros M key
to exit Free Xros M mode.
5.10 iScape
The iScape panoramic imaging feature extends your field of view by piecing together multiple
B images into a single, extended B image. Use this feature, for example, to view a complete
hand or thyroid.
When scanning, you move the probe linearly and acquire a series of B images, the system
pieces these images together into single, extended B image in real time. Besides, the system
supports out-and-back image piecing.
After you obtain the extended image, you can rotate it, move it linearly, magnify it, add
comments or body marks, or perform measurements on the extended image.
You can perform the iScape panoramic imaging feature on B (power) real time images.
CAUTION:
iScape panoramic imaging constructs an extended image from
individual image frames. The quality of the resulting image is user-
dependent and requires operator skill and additional practice to
become fully proficient. Therefore, the measurement results can be
inaccurate. Exercise caution when you perform measurements in
the iScape mode. Smooth even speed will help produce optimal
image results.
Tips:
 iScape is an optional module.
 The display of the biopsy guideline is not allowed in iScape mode.
5.10.1 Basic Procedures for iScape Imaging
To perform iScape imaging:
1. Connect an appropriate iScape-compatible probe. Make
sure that there is enough
coupling gel along the scan path.
2. Enter iScape:
