Chapter 7 Related Documents
Compound 2-stage Screw Compressor 3225**C Parts Configuration Table
7-27
7.2 Parts Configuration Table
Table 7-1 Parts Configuration Table
P/N
Part Name
Code No.
Remarks
Q’ty.
1-1
Main Rotor Casing (1)
CS00100-3225C1S
3225S**
1 (S*C)
1-1
Main Rotor Casing (1)
CS00100-3225C1M
3225M*
1 (M*C)
1-1
Main Rotor Casing (1)
CS00100-3225C1L
3225L**
1 (L*C)
1-1
Main Rotor Casing (1)
CS00100-3225C1LL
3225LL*
1(LL*C)
1-2
Main Rotor Casing (2)
CS00100-250S
250S**
1 (*SC)
1-2
Main Rotor Casing (2)
CS00100-250M
250M**
1 (*MC)
1-2
Main Rotor Casing (2)
CS00100-250L
250L**
1 (*LC)
2-1
Hexagon Socket Head Cap Screw
NB35424-080
M24×80
52
2-2
Hexagon Socket Head Cap Screw
NB35424-060
M20×60
44
3-1
Alignment Pin
NE2025-080
Φ25×80
4
3-2
Alignment Pin
NE2016-070
Φ16×70
4
4-1
Eye Bolt
NB600-30
M30
2
4-2
Eye Bolt
NB600-30
M30
1
5-1
Suction Cover (1)
CS00500-3225C1
3225**C
1
5-2
Suction Cover (2)
CS00500-3225C2
3225**C
1
6-1
Gasket, Suction Cover (1)
CS00600-320N
320***
1
6-2
Gasket, Suction Cover (2)
CS00600-3225CN
3225**C
1
7-1
Eye Bolt
NB600-16
M16
2
7-2
Eye Bolt
NB600-36
M36
1
8-1
Spring Pin (1)
NE3206-018
Φ6×18
2
8-2
Spring Pin (2)
NE3206-012
Φ6×12
2
10-1A
Plug
NF06-020
R3/4
1
10-1B
Plug
NF06-015
R1/2
1
10-2A
Plug
NF06-010
R3/8
1
10-2B
Plug
NF06-032
R1/4
1
10-2C
Plug
NF06-020
R3/4
1
10-2D
Plug
NF06-015
R1/2
1
10-2E
Plug
NF06-015
R1/2
1
10-2F
Plug
NF06-015
R1/2
1
11-1
Bearing Head (1)
CS01100-3225C1
3225**C
1
11-2
Bearing Head (2)
CS01100-3225C2
3225**C
1
12-1
Gasket, Bearing Head (1)
CS01200-320N
320***
1
12-2
Gasket, Bearing Head (2)
CS01200-250N
250***
1
13-1
Eye Bolt
NB0600-036
M36
2
13-2
Eye Bolt
NB0600-012
M12
1
14-1
Spring Pin (1)
NE3206-018
Φ6×18
2
14-2
Spring Pin (2)
NE3206-012
Φ6×12
2
15-1A
Plug
NF06-010
R3/8
1
15-1B
Plug
NF06-032
R1"1/4
1
15-1C
Plug
NF06-020
R3/4
1
16
Bearing Cover
CS01800-3225C
3225**C
1
17-1
Gasket, Bearing Cover (1)
CS01700-3225CN
3225**C
1
17-2
Gasket, Bearing Cover (2)
CS73300-3225CN
3225**C
1
