mycom 3225**C Series User Manual

2202MYJE-MY-C8-N_2018.02.
Chapter 7 Related Documents
Compound 2-stage Screw Compressor 3225**C Parts Configuration Table
7-33
P/N
Part Name
Code No.
Remarks
Q’ty.
421
O-ring
PA11-046
JIS B 2401 P46
2(*SC)(*MC)
423
Spacer, Unload Position (Low-stage)
CS42300-3225MSC
3225M*C
1 (M*C)
431
O-ring
PA11-140
JIS B 2401 P140
1 (M*C)
432-1
O-ring
PA12-165
JIS B 2401 G165
4
432-2
O-ring
PA12-130
JIS B 2401 G130
4
433-1
O-ring
PA12-165
JIS B 2401 G165
4
433-2
O-ring
PA12-130
JIS B 2401 G130
4
528
Sleeve with O-ring, Oil Seal
CS52809-320VD
320V**
1
529
Set Screw
NA83606-008
M6×8
2
605
Plug
NF06-025
R 1"
1
607-A
Plug
NF06-008
R 1/4
1
607-B
Plug
NF06-008
R 1/4
1
744
O-ring
PA12-090
JIS B 2401 G90
1
-
O-ring set
CS7109-0M
NBR 3225C
-
-
Gasket set
CS7118-0M
3225C
-
The sizes of O-ring No.432-2 and No.432-2 have been changed to G130 from G135 in October 2012
as a design change.
 The part code of the O-ring is the one assigned to NBR which is standard material.
When the material of the O-ring is other than NBR, a different part code is used for
each material.
If you are using O-rings made from other than the standard material, please contact
MAYEKAWA when placing an order.
