Configure Switching
106
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
The following table describes the nonconfigurable information on the page.
Configure Port PVID Settings
You can assign a port VLAN ID (PVID) to an interface. The following requirements apply to a
PVID:
• You must define a PVID for all ports.
• If no other value is specified, the default VLAN PVID is used.
• To change the port’s default PVID, you must first create a VLAN that includes the port as
a member.
 To configure PVID settings:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 9.
The login window opens.
Table 20. VLAN status
Field Definition
VLAN ID The VLAN identifier (VID) of the VLAN. The range of the VLAN ID is 1
to 4093.
VLAN Name The name of the VLAN. VLAN ID 1 is always named Default.
VLAN Type The VLAN type:
• Default (VLAN ID = 1). Always present.
• Static. A VLAN that you configured.
Member Ports The ports that are included in the VLAN.
