Manage Device Security
233
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
The following table describes the columns in the Interface Binding Status table on the page.
View or Delete MAC ACL Bindings in the MAC Binding Table
You can view or delete the MAC ACL bindings in the MAC Binding Table.
 To view or delete MAC ACL bindings:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 9.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Security > ACL > Basic > MAC Binding Table.
The previous figure shows examples.
6. To delete a MAC ACL-to-interface binding, do the following:
a. Select the check box next to the interface.
b. Click the Delete button.
Table 48. Interface Binding Status table
Field Description
Interface The interface of the ACL assigned.
Direction The selected packet filtering direction for the ACL.
ACL Type The type of ACL assigned to the selected interface and direction.
ACL ID The ACL number (for an IP ACL) or ACL name for a MAC ACL) identifying
the ACL assigned to the selected interface and direction.
Sequence Number The sequence number signifying the order of the specified ACL relative to
other ACLs assigned to the selected interface and direction.
