Manage Device Security
218
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
For more information, see Configure a Port Security Interface on page 215.
9. Select Security > Traffic Control > Port Security > Security MAC Address.
10. From the Port List menu, select the individual interface.
The Dynamic MAC Address Table displays the MAC addresses and their associated
VLANs that were learned on the selected port. The fields are described in the following
table.
11. To convert the dynamically learned MAC address to a statically locked addresses, select the
Convert Dynamic Address to Static check box.
12. Click the Apply button.
The dynamic MAC address entries are converted to static MAC address entries in a
numerically ascending order until the static limit is reached.
The Number of Dynamic MAC Addresses Learned field displays the number of
dynamically learned MAC addresses on a specific port.
13. To refresh the page with the latest information about the switch, click the Update button.
Configure Protected Ports
You can configure the ports as protected or unprotected. If a port is configured as protected,
it does not forward traffic to any other protected port on the switch, but it does forward traffic
to unprotected ports.
 To configure protected ports:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
Field Description
VLAN ID The VLAN ID corresponding to the MAC address.
MAC Address The MAC addresses learned on a specific port.
