Configure Switching
147
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
11. Click the Apply button.
The updated configuration is sent to the switch. Configuration changes take effect
immediately.
Configure the Multicast Forward All Option
After IGMP snooping is enabled, multicast packets are forwarded only to the members of
multicast groups. However, you can enable the Multicast Forward All option for an interface
so that the interface receives and forwards all multicast traffic on the VLAN.
 To enable the Multicast Forward All option for an interface:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 9.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Switching > Multicast > Static Multicast Address > Multicast Forward All.
6. From the VLAN ID menu, select the VLAN ID for the VLAN in which the multicast group is
located.
If a name is associated with the VLAN, the name displays in the VLAN Name field.
7. Select which type of interfaces display onscreen:
• To display physical ports only, click the 1 link.
To Next Page
