18 NIBE F1330
Installation / Adjustment
Description of functions - Start up
11. Set the heat pump’s operating type to External control
in menu 0.2.1.
12. Remove the strap for compressor A (KPRAA).
13. Compressor A starts. Note there may be a slight delay
of a few minutes before starting. See menu 0.1.1 to see
the time to start.
14. Check the temperature difference on the heat medium
in menu 5.2.1. Nominal difference is 5 to 10 °C.
15. Check the temperature difference on the brine medium
in menu 5.2.2. Nominal difference is 2 to 5 °C.
16. Reset the strap for compressor A (KPRAA).
17. Remove the strap for compressor B (KPRAB).
18. Compressor B starts. Note there may be a slight delay
of a few minutes before starting. See menu 0.1.2 to see
the time to start.
19. Check the temperature difference on the heat medium
in menu 5.3.1. Nominal difference is 5 to 10 °C.
20. Check the temperature difference on the brine medium
in menu 5.3.2. Nominal difference is 2 to 5 °C.
21. Reset the strap for compressor B (KPRAB).
22. Reset all settings by selecting Extended in menu 5.4.10.
Note that the setting returns to Off as soon as the heat
pump has made the factory setting.
23. Set the power switch (8) in position ”0”.
24. Remove both straps (KPRAA and KPRAB).
When all heat pumps have undergone this inspection,
continue with “Description of functions” - “Start up” >
“Start up with a F1330” or if several F1330 are connected
“Description of functions” - “Start up” > “Start up with
several F1330s in a system”
See “Dealing with malfunctions” at the end of the
booklet in the event of any problems at start-up.
Start up with a F1330
1. Start the heat pump by turning the power switch (8)
to the 1 position. The unit will now enter screen saver
mode and the text Master will be shown on the bot-
tom row of the display.
2. When only Connecting flashes the heat pump this may
be because the heat pump is set as a Slave. If so, set
the unit as the Master according to the instructions in
Description of Functions - Start up > Master/Slave.
3. Deactivate the screen saver by holding down the but-
ton in the far left corner and the enter button for ap-
proximately 8 seconds. (See the section the Description
of Functions - Start up > Screensaver.)
4. Set in the Service position from menu 8.1.1. (See the
example in Control > Changing parameters.)
5. Set the heat pump’s operating type, i.e. whether the
heat pump should produce hot water and/or heating.
This is done in menu 0.2.1. (See the section Description
of Functions - Start up > Operating type selection.)
6. Continue the start up settings with the help of
Description of Functions - Basic Functions. Connect and
configure the pertinent functions for the installation.
