29NIBE F1330
Installation / Adjustment
Description of functions - Basic functions
Quick guide - menu settings oil boiler
Menu 9.1.8 Additive [S]
Whether additional heat is to be engaged is set here. The
options are: Off, Electricity, Oil or Electri/Oil. The factory
setting is Off.
In order for the oil boiler to be active the option Oil or
Electri/Oil must be selected in this menu. When Electri/
Oil is selected, oil is used for additional output when the
input Tariff A (TA) is broken, otherwise electricity is used.
Menu 8.2.5 Additive start value [U]
Here you select at which degree-minute setting the first
additional heater step shall start for heating. The value is
adjustable between -3000 and 0.
The factory setting is -500.
Menu 6.3.1 Oil Boiler time [U]
Number of hours the oil boiler shall be active.
The value can be set between 1 and 24 hours.
The factory setting is 12 hours.
Menu 6.3.2 Start temp. shunt [U]
Here you select the temperature on the boiler sensor (PG)
at which the boiler shunt (SV-P) shall start to regulate.
Adjustable between 10 and 90 °C.
The factory setting is 55 °C.
The outline diagram with docking instructions is
available at www.nibe.eu
Gas boiler
In those cases, additional heating is supplied using a gas
boiler you can choose to connect it as an oil boiler if you
need to control a shunt valve or alternatively connect it as
an electric boiler.
See the section Description of functions - Basic functions >
Electrical additional heater to connect it as an electric boiler
and the section Description of functions - Basic
functions > Oil boiler to connect it as an oil boiler.
Outdoor air collector
Outdoor air collector AMB 30 is connected to NIBE F1330
for only outdoor air operation or in combination with rock/
ground collector (hybrid operation).
Outdoor air operation
During outdoor air operation the AMB 30 uses the out-
door air as a heat source and operation is permitted down
to an outdoor air temperature of approx -12 °C. Outgoing
brine from the F1330 is connected directly to the air mod-
ule. When the outdoor air temperature is lower than the
dimensioned balance temperature (the lowest temperature
where the heat pump can manage all the heating) the ad-
ditional heat must be accessible to supplement the heat
pump.
Hybrid operation
When the outdoor air temperature is higher than 12 °C the
control switches the reversing valves to operation with only
AMB 30. When the outdoor air temperature is between
approx. 0 and 10 °C the controls switches the reversing
valve to operation with both AMB 30 and ground/rock col-
lector (hybrid operation). At a set min. difference the con-
trol switches to operation with only ground/rock collector.
Connection
See documentation for AMB30.
