66 NIBE F1330
Control
Menu 8.2.0 Operatingmodesetting [U]
Pressing the enter button takes you to sub-menus for the
operating mode settings.
Menu 8.2.1 Only additional heat [U]
You select here whether additional mode should be ac-
tivated. Can be set to Yes or No. When additional mode
is activated the compressors are blocked and additional
heating and circulation pump can not be blocked using the
operating mode button. The factory setting is No.
Menu 8.2.2 Changing temperature [U]
At this average outdoor temperature, the heat pump
changes operating mode when auto mode is selected. The
value is adjustable between 10 and 40 °C. The factory set-
ting is 25 °C.
Menu 8.2.3 Start value compr. [U]
Here you select at which degree minute setting the first
compressor shall start for heating. The value is adjustable
between -3000 and +100. The factory setting is -60.
Menu 8.2.4 GM for compr.step [U]
Here you set how many degree-minutes shall pass between
each compressor stage. The value is adjustable between 0
and 500. The factory setting is 60.
Menu 8.2.5 Additive start value [U]
Here you select at which degree-minute setting the first ad-
ditional heater step shall start for heating. The value is ad-
justable between -3000 and 0. The factory setting is -500.
Menu 8.2.6 GM for additive step [U]
Here you set how many degree-minutes shall pass between
each additional heater step. The value is adjustable be-
tween 10 and 500. The factory setting is 100.
Menu 8.2.7 Flow diff HP [U]
The largest deviation from the calculated flowtemperature
before forced control comes into effect is set here. The
value is adjustable between 1 and 20 °C. The factory set-
ting is 13 °C.
Menu 8.2.8 Diff HP-Add [U]
When the current flow temperature differs from that calcu-
lated by this value plus the value in menu 8.2.7, a further
additional step is force connected or disconnected. The
value is adjustable between 1 and 20 °C. The factory set-
ting is 3 °C.
Menu 8.2.9 Return [U]
Pressing the enter button returns you to menu 8.2.0.
Menu 8.3.0 Load monitor [U]
Pressing the enter button takes you to sub-menus where
readings and settings concerning the load monitor are
made.
Menu 8.3.1 Fuse size [U]
The setting (16, 20, 25, 35, 50 or 63 A) selected on the
EBV-card (2) knob (100) is shown here.
Menu 8.3.2 Max electric power [U]
The setting (variable between 10 and 100 %) selected on
the EBV-card (2) knob (101) is shown here.
Menu 8.3.3 - 8.3.5 Current phase 1-3 [U]
Shows the measured current from the current sensor,
phase 1 - 3.
When the current falls below 2.0 A, low is shown on the
display.
Menu 8.3.6 Ratio of transf. EBV [U]
The transfer value must be defined depending on the cur-
rent transformers used for the EBV card. This is done in
this menu. The value is adjustable between 100 and 900 in
increments of 10. The setting 300 applies for the supplied
current transformers. The factory setting is 300.
Menu 8.3.7 Tariff status [U]
Shows the current tariff status.
Menu 8.3.8 Return [U]
Pressing the enter button returns you to menu 8.3.0.
Menu 8.4 Return [N]
Pressing the Enter button returns you to menu 8.0.
9.0 Service menus
Menu 9.1.0 System settings [S]
Pressing the enter button takes you to sub-menus for the
system settings.
Menu 9.1.1 Expansion card 11 [S]
Here the expansion card 11 is set On or Off. The factory
setting is Off.
Menu 9.1.2 Expansion card 12 [S]
Here the expansion card 12 is set On or Off. The factory
setting is Off.
Menu 9.1.3 RCU [S]
Here the RCU is set On or Off. The factory setting is Off.
Menu 9.1.4 Sub shunt [S]
Here the sub shunt is set either On or Off. The factory set-
ting is Off.
Menu 9.1.5 Pool [S]
Here pool heating is set either On or Off. The factory set-
ting is Off.
Menu 9.1.6 Hot water acc. tank [S]
Charging the hot water to a single-jacketed accumulator
via a heat exchanger. Here the hot water accumulator is set
either On or Off. The factory setting is Off.
[N]
Normal menus: displayed in all menu modes.
[U]
Extended menus: Only displayed when extended or
service is selected in menu 8.1.1.
[S]
Service menus: Only displayed when service is selected
in menu 8.1.1.
