57NIBE F1330
Control
Control
Menu 1.9.0 Hot water with additional heat [U]
This menu is displayed if “On” is selected in menu 9.1.12.
Menu 1.9.1 Start temperature additional heat [U]
The temperature at which additional heat is to start is
shown here. The value is adjustable between 5 and 70 °C.
The factory setting is 45 °C.
Menu 1.9.2 Stop temperature additional heat [U]
The temperature at which additional heat is to stop is se-
lected here. The value can be adjusted between 5 and 70
°C.
The factory setting is 50 °C.
Meny 1.9.3 Return [U]
Pressing the enter button returns you to menu 1.9.0
Menu 1.10 Return [N]
Pressing the enter button returns you to menu 1.0
2.0 Flow temperature
Menu 2.1 Curve slope [N]
The selected curve slope for the heating curve is shown
here. The value is adjustable between curve 1 and 15, or
in position Own curve. The values for own curve are set in
menu 2.6.0. The factory setting is 9.
Menu 2.2 Offset heating curve [N]
The chosen offset for the heating curve is shown here. The
value is adjustable between -10 and +10. NOTE! The value
cannot be changed using the plus and minus buttons, only
by using the Offset heating curve knob on the Master unit.
If the RCU is connected, the set offset is shown via RCU
between brackets. The actual offset then becomes the total
of the set offset and RCU offset.
Menu 2.3 Min. flow temp. [U]
The set minimum level for the flow temperature to the
heating system is shown here. The calculated supply tem-
perature never drops below this level irrespective of the
outdoor temperature, curve slope or offset heating curve.
The value is adjustable between 2 and 65 °C. The factory
setting is 15 °C.
Menu 2.4 Max. flow temp. [U]
The set maximum level for the supply temperature to the
heating system is shown here. The calculated supply tem-
perature never exceeds this level irrespective of the outdoor
temperature, curve slope or offset heating curve. The value
is adjustable between 10 and 80 °C. The factory setting is
55°C.
Menu 2.5 External adjustment [U]
When the thermostat is selected in menu 9.1.11, you can
connect an external contact, see Description of functions -
Basic functions > Room control. Using an external contact,
for example, a room thermostat or a timer allows you to
temporarily or periodically raise or lower the flow tempera-
ture and with that the room temperature. When the exter-
nal contact is made, the heating curve offset is changed by
the number of steps shown here. The value is adjustable
between -10 and +10. The factory setting is 0.
Menu 2.6.0 Own curve definition [U]
Your own curve definition is chosen here. This is an indi-
vidual linear curve with one break point. You select a break
point and the associated temperatures. NOTE! The Curve
slope in menu 2.1 must be set to Own curve to activate
this.
Menu 2.6.1 Flow temp. at -20 ºC [U]
The flow temperature is selected here with at an outdoor
temperature of -20 °C. The value is adjustable between 10
and 80 °C. The factory setting is 55 °C.
Menu 2.6.2 Flow temp. at +20 ºC [U]
The flow temperature is selected here with at an outdoor
temperature of +20 °C. The value is adjustable between 10
and 80 °C. The factory setting is 18 °C.
Menu 2.6.3 Set buckling temp. [U]
Here you select at what outside temperature the break
point shall occur. The value is adjustable be-tween -15 and
+15 °C. The factory setting is0 °C.
Menu 2.6.4 Flowtemp. at buckling [U]
You set the required flow temperature for the break point
here. The value is adjustable between 10 and 80 °C. The
factory setting is 40 °C.
Menu 2.6.5 Return [U]
Pressing the enter button returns you to menu 2.6.0.
Menu 2.7.0 Fixed condensing [U]
Pressing the enter button takes you to the sub-menus,
which show the settings for fixed condensing. Only shown
when fixed condensing is selected in menu 9.1.7.
Menu 2.7.1 Starttemp.compressor [U]
Temperature on the flow line sensor (FG) when first com-
pressor starts. The value is adjustable between 5 and 60
°C. The factory setting is 47 °C.
Menu 2.7.2 Stoptemp. compressor [U]
Temperature on the flow line sensor (FG) when the last
compressor stops. The value is adjustable between 5 and
60 °C. The factory setting is 50 °C.
Menu 2.7.3 Starttemp. additive [U]
Temperature on the flow line sensor (FG) when additional
heating engages. The value is adjustable between 5 and 60
°C. The factory setting is 45 °C.
[N]
Normal menus: displayed in all menu modes.
[U]
Extended menus: Only displayed when extended or
service is selected in menu 8.1.1.
[S]
Service menus: Only displayed when service is selected
in menu 8.1.1.
