58 NIBE F1330
Control
Menu 2.7.4 Stoptemp. additive [U]
Temperature on the flow line sensor (FG) when additional
heating disengages. The value is adjustable between 5 and
60 °C. The factory setting is 49 °C.
Menu 2.7.5 Return [U]
Pressing the Enter button returns you to menu 2.7.0.
Menu 2.8 Return temperature [N]
The current temperature of the return water (RG) from the
heating system is shown here.
Menu 2.9 Degree minutes [N]
Current value for number of degree-minutes. This value
can be changed to e.g. accelerate the start of heat produc-
tion. The value is adjustable in increments of 10.
Menu 2.10 Return [N]
Pressing the Enter button returns you to menu 2.0.
3.0 Flow temperature 2*
* Accessories
Menu 3.1 Curve slope 2 [N]
The selected curve slope for the heating curve is shown
here. The value is adjustable between curve 1 and 15, or
in position Own curve. The values for own curve are set in
menu 3.6.0. The factory setting is 9.
Menu 3.2 Offset heatingcurve 2 [N]
The chosen offset for the heating curve is shown here. The
value is adjustable between -10 and +10. The factory set-
ting is 0.
If the RCU is connected, the set offset is shown via RCU
between brackets. The actual offset then becomes the total
of the set offset and RCU offset.
Menu 3.3 Min. flow temp. 2 [U]
The set minimum level for the flow temperature to the
heating system is shown here. The calculated supply tem-
perature never drops below this level irrespective of the
outdoor temperature, curve slope or offset heating curve.
The value is adjustable between 10 and 65 °C. The factory
setting is 15 °C.
Menu 3.4 Max. flow temp. 2 [U]
The set maximum level for the supply temperature to the
heating system is shown here. The calculated supply tem-
perature never exceeds this level irrespective of the outdoor
temperature, curve slope or offset heating curve. The value
is adjustable between 10 and 80 °C. The factory setting is
55 °C.
Menu 3.5 External adjustment 2 [U]
When the thermostat is selected in menu 9.1.11, you can
connect an external contact, see Description of functions -
Basic functions > Room control. Using an external contact,
for example, a room thermostat or a timer allows you to
temporarily or periodically raise or lower the flow tempera-
ture and with that the room temperature. When the exter-
nal contact is made, the heating curve offset is changed by
the number of steps shown here. The value is adjustable
between -10 and +10. The factory setting is 0.
Menu 3.6.0 Own curve definite. 2 [U]
Your own curve definition is chosen here. This is an indi-
vidual linear curve with one break point. You select a break
point and the associated temperatures. NOTE! The Curve
slope in menu 3.1 must be set to Own curve to activate
this.
Menu 3.6.1 Flow temp. at -20 ºC [U]
The flow temperature is selected here at an outdoor tem-
perature of -20 °C. The value is adjustable between 10 and
80 °C. The factory setting is 55 °C.
Menu 3.6.2 Flow temp. at +20 ºC [U]
The flow temperature is selected here at an outdoor tem-
perature of +20 °C. The value is adjus-table between 10
and 80 °C. The factory setting is 18 °C.
Menu 3.6.3 Set buckling temp. [U]
Here you select at what outside temperature the break
point shall occur. The value is adjustable between -15 and
+15 °C. The factory setting is 0 °C.
Menu 3.6.4 Flowtemp.at buckling [U]
You set the required flow temperature for the break point
here. The value is adjustable between 10 and 80 °C. The
factory setting is 40.
Menu 3.6.5 Return [U]
Pressing the enter button returns you to menu 3.6.0.
Menu 3.7 Return temperature 2 [U]
The current temperature of the return water (RG2) from
the heating system is shown here.
Menu 3.8 Shunt period time [U]
Here you select the period time, i. e. the time between
corrections for the sub shunt (SV-V2). The value is adjust-
able between 10 and 500 seconds. The factory setting is
120 seconds.
Menu 3.9 Shunt intensificat. [U]
Here you select how many seconds the sub shunt (SV-V2)
shall run in relation to the difference between the calcu-
lated flow and the true flow. For example, a difference of
2 degrees and a set amplification of 5 gives 10 seconds in
control of the sub shunt. The value is adjustable between
1 and 10. The factory setting is 1.
Menu 3.10 Return [N]
Pressing the Enter button returns you to menu 3.0.
[N]
Normal menus: displayed in all menu modes.
[U]
Extended menus: Only displayed when extended or
service is selected in menu 8.1.1.
[S]
Service menus: Only displayed when service is selected
in menu 8.1.1.
