27NIBE F1330
Installation / Adjustment
Description of functions - Basic functions
Quick guide - menu settings
electrical additional heater
Menu 9.1.8 Additive [S]
Whether additional heat is to be engaged is set here. The
options are: Off, Electricity, Oil or Electri/Oil. The factory
setting is Off.
In order for the electrical additional heater to be active
the option Electricity or Electri/Oil must be selected in
this menu. When Electri/Oil is selected, electricity is used
for the additional output when the input Tariff A (TA) is
short-circuited, otherwise oil is used.
Menu 8.2.5 Additive start value [U]
Here you select at which degree-minute setting the first
additional heater step shall start for heating. The value is
adjustable between -3000 and 0. The factory setting is
-500.
Menu 8.2.6 GM for additive step [U]
Here you set how many degree-minutes shall pass be-
tween each additional heater step. The value is adjustable
between 10 and 500. The factory setting is 100.
Menu 8.3.1 Fuse size [U]
The setting selected on the ”EBV card” (2) knob (100) is
shown here.
Examples of ”Binary control” with 3 relays:
Step ETS-1 ETS-2 ETS-3
0---
1 230 V - -
2 - 230 V -
3 230 V 230 V -
4 - - 230 V
5 230 V - 230 V
6 - 230 V 230 V
7 230 V 230 V 230 V
Menu 8.3.2 Max electric power [U]
The setting selected on the ”EBV card” (2) knob (101) is
shown here.
Menu 6.2.1 Immersionheater type [U]
Here you select whether immersion heater control shall
take place in binary or linear.
”Binary control” means that stepping is carried out ac-
cording to the binary system and in doing so makes it
possible to control a maximum of 63 electrical steps.
”Linear control” gives a maximum of 6 electrical steps
when stepping is carried out according to the linear in-
crease model.
Menu 6.2.2 Immersionheatrelays [U]
Here you select how many relays are connected to the
electrical additional for heat production. Adjustable
between 1 and 6. The factory setting is 3.
Menu 6.2.3 Steps at 2h delay [U]
The number of permitted electrical steps within 2 hours
of start up. Adjustable between 0 and 63. The factory
setting is 3.
Examples of ”Linear control” with 3 relays:
Step ETS-1 ETS-2 ETS-3
0---
1 230 V - -
2 230 V 230 V -
3 230 V 230 V 230 V
The outline diagram with docking instructions is
available at www.nibe.eu
