3. Sett
Initial Settings
Press the [3] key on the MENU screen to display the
initial settings menu.
3
MENU: 3. Set
• The items shown in a box (eg. VA zero direction ) in “Conditions” column are Job
Settings that can not be changed once a Job is created.
• If any of them are changed while a Job is open, a
confirmation screen is shown to ask you to create a
new Job with the new settings or to work with those
settings without recording any data. (See p.8-7)
Menu Item Conditions
VA zero direction
Zenith/Horizon/Compass
<Angle Resolution>
DTM552=0.5”/1”/5”
DTM532=1”/5”/10”
DTM522=1”/5”/10”
<HA corr.>*
OFF/ON
HA**
0 to BS / Azimuth
1:Angle
* When set to “ON”, ACH and Trunnion axis compensation is
applied to horizontal angle readings.
** When it is set to “Azimuth”, horizontal angle (HA) shown and
recorded to the Job is in Azimuth value.
With the “0 to BS” setting, HA shown and recorded is in HA
zero to BS value.
3-97
