Nikon Z 7II User Manual

493
B
The Setup Menu: Camera Setup
D
Computer USB Power Delivery
•
Before using a computer to supply power to the camera, check that the
computer is equipped with a Type C USB connector. Use a UC-E25 USB
cable (available separately) to connect the camera to the computer.
•
Depending on the model and product specifications, some computers
will not supply current to power the camera.
D
“Power Delivery” Versus “Charging”
The supply of power for camera operations is referred to as “power
delivery”, while the term “charging” is used when power is supplied only
to charge the camera battery. The conditions under which the power
supplied by external devices is used to power the camera or charge the
battery are shown below.
1 Includes instances in which the power switch is in the “OFF” position
but Bluetooth upload is in progress or the memory card access lamp is
lit.
2 EN-EL15c and EN-EL15b batteries inserted in the camera will charge
when the camera is connected to a charging AC adapter (available
separately for the Z 6II, supplied with the Z 7II) or via USB to a
computer.
Option selected for
[USB power delivery]
Camera
External power
source used for
[Enable]
On
1
Power delivery
Off Charging
2
[Disable]
On
1
—
Off Charging
2

Nikon Z 7II Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Sensor Size	35.9 x 23.9 mm
Effective Megapixels	45.7 MP
ISO Sensitivity	64-25600 (expandable to 32-102400)
Image Processor	Dual EXPEED 6
Continuous Shooting Speed	10 fps
Video Recording	4K UHD up to 60p
Weather Sealing	Yes
Connectivity	Wi-Fi, Bluetooth
Viewfinder	3.69M-dot OLED
LCD Screen	3.2-inch tilting touchscreen, 2.1M dots
Battery	EN-EL15c
Battery Life	Approx. 420 shots per charge (CIPA standard)
Weight	705 g (body only)
Dimensions	134 x 100.5 x 69.5 mm
Autofocus System	Hybrid phase-detection/contrast AF with 493 points
