Omron E5AN-H User Manual

95
Executing Heating/Cooling Control Section 4-4
Automatic Cooling
Coefficient Adjustment
By executing AT during heating/cooling control, the cooling coefficient can be
automatically calculated along with the PID parameters.
Note If there is strong non-linear gain for the cooling characteristics, such as when
cooling water boils for cooling control, it may not be possible to obtain the opti-
mum cooling coefficient at the Controller, and control may take the form of
oscillating waves. If that occurs, increase the proportional band or the cooling
coefficient to improve control.
4-4-2 Settings
To set heating/cooling control, set the Standard or Heating/Cooling, Dead
Band, and Cooling Coefficient parameters.
Setting Heating/Cooling Control
Operating Procedure Standard or heating/cooling = Heating/cooling
Setting the Cooling Coefficient
Operating Procedure PID 1 Cooling Coefficient = 10
Setting the Dead Band
Operating Procedure Dead Band = 5
Parameter name Setting rage Default
Automatic Cooling Coef-
ficient Adjustment
OFF: Disabled, ON: Enabled OFF
Initial Setting Level
1. Press the O Key for at least three seconds to move from the operation
level to the initial setting level.
2. Select “heating/cooling control” in the initial setting level.
stnd: Standard control
h-c: Heating/cooling control
s-hc
stnd
Standard or
Heating/
Cooling
PID Setting Level
1. Press the O Key to move from the operation level to the PID setting level.
The current PID set number will be displayed. Use the U or D Key to
select 1.
2. Select the PID1 Cooling Coefficient parameter by pressing the M Key.
3. Press the U and D Keys to set 10.00.
d.pid
1
Display PID
selection
1.csc
1.00
PID1 Cooling
Coefficient
1.csc
10.00
Adjustment Level
1. Select the Dead Band parameter in the adjustment level.
2. Use the U Key to set the parameter to 5.0.
C
c-db
0.0
Dead Band
C
c-db
5.0
