Appendix
Parameter Operation Lists
Operation Level
Note (1) The parameters in the current bank will be accessed.
Parameters Characters Setting (monitor) value Display Default Unit Set value
Process Value Temperature: According to
indication range for each sen-
sor.
Analog: Scaling lower limit
−5% FS to Scaling upper limit
+5% FS
EU
Set Point (See note
1.)
SP lower limit to SP upper
limit
0EU
Auto/Manual Switch a-m
Bank No. bank 0 to 7 (See note 2.) 0 None
Remote SP Monitor rsp Remote SP upper limit to
Remote SP lower limit
EU
Set Point During SP
Ramp
sp-m SP lower limit to SP upper
limit
EU
Heater Current 1
Value Monitor
ct1 0.0 to 55.0 A
Heater Current 2
Value Monitor
ct2 0.0 to 55.0 A
Leakage Current 1
Monitor
lcr1 0.0 to 55.0 A
Leakage Current 2
Monitor
lcr2 0.0 to 55.0 A
Program Start prst RSET, STRT rset, strt RSET None
Soak Time Remain sktr 0 to 9999 min or h
RUN/STOP r-s RUN/STOP run, stop Run None
Alarm Value 1
(See note 1.)
al-1 −19999 to 32400 0.0 EU
Alarm Value Upper
Limit 1 (See note 1.)
al1h −19999 to 32400 0.0 EU
Alarm Value Lower
Limit 1 (See note 1.)
al1l −19999 to 32400 0.0 EU
Alarm Value 2
(See note 1.)
al-2 −19999 to 32400 0.0 EU
Alarm Value Upper
Limit 2 (See note 1.)
al2h −19999 to 32400 0.0 EU
Alarm Value Lower
Limit 2 (See note 1.)
al2l −19999 to 32400 0.0 EU
Alarm Value 3
(See note 1.)
al-3 −19999 to 32400 0.0 EU
Alarm Value Upper
Limit 3 (See note 1.)
al3h −19999 to 32400 0.0 EU
Alarm Value Lower
Limit 3 (See note 1.)
al3l −19999 to 32400 0.0 EU
MV Monitor
(Heating)
o −5.0 to 105.5 (standard)
0.0 to 105.0 (heating/cooling)
%
MV Monitor
(Cooling)
c-o 0.0 to 105.0 %
Valve Opening Moni-
tor
v-m −10.0 to 110.0 %
