Setting the Width of MV Variation Section 4-19
4-19 Setting the Width of MV Variation
MV Change Rate Limit
Operating Procedure This procedure sets the MV change rate limit to 5.0%/s. The related parame-
ters are as follows:
PID·ON/OFF = PID
ST = OFF
Operation Level
5. Press the O Key for at least one second to move from the initial setting
level to the operation level.
Adjustment Level
6. Press the O Key to move from the operation level to the adjustment level.
7. Select the Extraction of Square Root Low-cut Point parameter by press-
ing the M Key.
8. Use the U Key to set the parameter to −10.0.
Operation Level
9. Press the O Key to return to the operation level.
C
25.0
100.0
PV/SP
l.adj
sqrp
0.0
Extraction of
Square Root
Low-cut Point
sqrp
10.0
Extraction of
Square Root
Low-cut Point
C
25.0
100.0
PV/SP
MV Change Rate Limit (Heating)
• The MV change rate limit sets the maximum allowable width of change
in the MV per second. If the change in the MV exceeds this setting, the
MV will be changed by the MV change rate limit until the calculated
value is reached. This function is disabled when the setting is 0.0.
• The MV change rate limit does not function in the following situations:
• In manual mode
• During ST execution (Cannot be set when ST is ON.)
• During AT execution
• During ON/OFF control
• While stopped (during MV at Stop output)
• During MV at PV Error output
orl
0.0
Parameter name Setting rage Unit Default
MV Change Rate
Limit
0.0 to 100.0 %/s 0.0
