Operation Level Section 5-3
The process value is displayed on the No. 1 display, and nothing is displayed
on the No. 2 and No. 3 (E5AN/EN-H only) displays.
During temperature input, the decimal point position depends on the currently
selected sensor, and during analog input it depends on the Decimal Point
parameter setting.
■ Related Parameters
Input type: Page 224, Set point upper limit, Set point lower limit: Page 227 (ini-
tial setting level)
The process value is displayed on the No. 1 display, and the set point is dis-
played on the No. 2 display.
During temperature input, the decimal point position depends on the currently
selected sensor, and during analog input it depends on the Decimal Point
parameter setting.
No. 3 Display (E5AN/EN-H)
The following table shows the contents of the No. 3 display, according to the
setting of the PV/SP Display Screen Selection parameter.
Process Value
The Additional PV Display parameter
must be set to ON.
Monitor range Unit
Process value Temperature: According to indication range for
each sensor.
Analog: Scaling lower limit −5% FS to Scaling
upper limit +5% FS (Refer to page 335.)
EU
Function
Monitor
See
See
Process Value/Set Point (Display 1)
(The Process Value/Set Point (Dis-
play 2) parameter is supported for
the E5AN-H and E5EN-H only.)
Process Value/Set Point (Display 2)
Monitor range Unit
Process value Temperature: According to indication range for
each sensor.
Analog: Scaling lower limit −5% FS to Scaling
upper limit +5% FS (Refer to page 335.)
EU
Setting range Unit
Set point SP lower limit to SP upper limit EU
Set value Display contents
0 Only the PV and SP are displayed. (The No. 3 display is not
shown.)
1 PV/SP/Bank No. and PV/SP/MV are displayed in order.
Function
Monitor
