Omron E5AN-H User Manual

315
Appendix
Bank Setting Level
Parameters Characters Setting (monitor) value Display Default Unit Set
value
Display Bank Selec-
tion
d.bnk 0 to 7 (See note 1.) None
Bank 0 SP 0.lsp SP lower limit to SP upper
limit
0.0 EU
Bank 0 PID Set No. 0.pid 0 to 8 (0: Auto selection) 1 None
Bank 0 SP Ramp
Set Value
0.spr OFF, 1 to 32400 off, 1 to 32400 OFF EU/s,
EU/min,
EU/h
Bank 0 Alarm Value
1
0.al1 −19999 to 32400 0.0 EU
Bank 0 Alarm Value
Upper Limit 1
0.a1h −19999 to 32400 0.0 EU
Bank 0 Alarm Value
Lower Limit 1
0.a1l −19999 to 32400 0.0 EU
Bank 0 Alarm Value
2
0.a-2 −19999 to 32400 0.0 EU
Bank 0 Alarm Value
Upper Limit 2
0.a2h −19999 to 32400 0.0 EU
Bank 0 Alarm Value
Lower Limit 2
0.a2l −19999 to 32400 0.0 EU
Bank 0 Alarm Value
3
0.a-3 −19999 to 32400 0.0 EU
Bank 0 Alarm Value
Upper Limit 3
0.a3h −19999 to 32400 0.0 EU
Bank 0 Alarm Value
Lower Limit 3
0.a3l −19999 to 32400 0.0 EU
Bank 0 Soak Time 0.sok 0 to 9999 1 min or h
Bank 0 Wait Band 0.wtb Temperature input: OFF,
0.1 to 3240.0
off, 0.1 to 3240.0 OFF °C or °F
Analog input: OFF, 0.01 to
99.99
off, 0.01 to 99.99 %FS
Bank 1 SP 1.lsp SP lower limit to SP upper
limit
0.0 EU
to
Bank 1 Wait Band 1.wtb Temperature input: OFF,
0.1 to 3240.0
off, 0.1 to 3240.0 OFF °C or °F
Analog input: OFF, 0.01 to
99.99
off, 0.01 to 99.99 %FS
Bank 2 SP 2.lsp SP lower limit to SP upper
limit
0.0 EU
to
Bank 2 Wait Band 2.wtb Temperature input: OFF,
0.1 to 3240.0
off, 0.1 to 3240.0 OFF °C or °F
Analog input: OFF, 0.01 to
99.99
off, 0.01 to 99.99 %FS
Bank 3 SP 3.lsp SP lower limit to SP upper
limit
0.0 EU
to
Bank 3 Wait Band 3.wtb Temperature input: OFF,
0.1 to 3240.0
off, 0.1 to 3240.0 OFF °C or °F
Analog input: OFF, 0.01 to
99.99
off, 0.01 to 99.99 %FS
