Output Adjustment Functions Section 4-17
4-17 Output Adjustment Functions
4-17-1 Output Limits
• Output limits can be set to control the output using the upper and lower
limits to the calculated MV.
• The following MV takes priority over the MV limits.
Manual MV (See note.)
MV at stop
MV at PV error
16. Use the U and D Keys to set the parameter to 1.
17. Press the M Key to select the Bank 1 SP parameter.
18. Use the U and D Keys to set the parameter to 200.0.
19. Press the M Key to select the Bank 1 Soak Time parameter.
20. Use the U and D Keys to set the parameter to 10.
21. Press the M Key to select the Bank 1 Wait band parameter.
22. Use the U and D Keys to set the parameter to 5.0.
23. Press the O Key to move from the bank setting level to the operation lev-
el.
Operation Level
d.bnk
0
Display Bank
Selection
d.bnk
1
1.lsp
0.0
Bank 1 SP
1.lsp
200.0
1.sok
1
Bank 1
Soak Time
0.sok
10
1.wtb
off
Bank 1
Wait band
1.wtb
5.0
C
25.0
100.0
PV/SP
