297
Appendix
Specifications
Ratings
Note (1) For the setting ranges for each sensor input, see page 335.
(2) When connecting the ES2-THB, connect it 1:1.
(3) The E5AN-H and E5EN-H Output Units are sold separately. Refer to the following table.
Supply voltage 100 to 240 VAC, 50/60 Hz 24 VAC, 50/60 Hz/24 VDC
Operating voltage range 85% to 110% of rated supply voltage
Power consump-
tion
E5CN-H 8.5 VA 5.5 VA/3.5 W
E5AN-H 12 VA 8.5 VA/5.5 W
E5EN-H 12 VA 8.5 VA/5.5 W
Sensor input (See note 1.) Temperature input
Thermocouple: K, J, T, E, L, U, N, R, S, B, W, PLII
Platinum resistance thermometer: Pt100, JPt100
Controllers with Analog (See note 2.)
Current input: 4 to 20 mA, 0 to 20 mA (Input impedance: 150 Ω max.)
Voltage input: 1 to 5 V, 0 to 5 V, 0 to 10 V (Input impedance: 1 MΩ max.)
Control output (See note 3.) Relay output E5CN-H Relay output:
SPST-NO, 250 VAC, 3 A (resistive load), electrical dura-
bility: 100,000 operations
Min. applicable load: 5 V, 10 mA
E5AN-H
E5EN-H
Relay output: Open and close
SPST-NO, 250 VAC, 1 A (including inrush current), elec-
trical durability: 100,000 operations
Min. applicable load: 5 V, 10 mA
Voltage output E5CN-H Output voltage 12 VDC ±15% (PNP), max. load current
21 mA, with short-circuit protection circuit
Current output E5CN-H 4 to 20 mA DC, 0 to 20 mA DC, Load: 600 Ω max.,
Resolution: approx. 10,000
Linear voltage
output
E5CN-H 0 to 10 VDC,
Load: 1 kΩ min., Resolution: approx. 10,000
SSR output E5AN-H
E5EN-H
75 to 250 VAC , 1A (resistive load)
Auxiliary output E5CN-H SPST-NO, 250 VAC, 3 A (resistive load), electrical durability: 100,000
operations
Min. applicable load: 5 V, 10 mA
E5AN-H
E5EN-H
SPST-NO, 250 VAC, 3 A (resistive load), electrical durability: 100,000
operations
Min. applicable load: 5 V, 10 mA
Control method 2-PID or ON/OFF control
Setting method Digital setting using front panel keys
Indication method 11-segment/7-segment digital display and single-lighting indicator
Other functions Depend on the model
Ambient temperature −10 to 55°C (with no condensation or icing); with 3-year guarantee: −10 to 50°C
Ambient humidity 25% to 85%
Storage temperature −25 to 65°C (with no condensation or icing)
Altitude 2,000 m or less
Recommended fuse T2A, 250 VAC, time lag, low shut-off capacity
Installation environment Installation Category II, Pollution Class 2 (IEC 61010-1 compliant)
