Counting Control Output ON/OFF Operations Section 4-21
4-21 Counting Control Output ON/OFF Operations
4-21-1 Control Output ON/OFF Count Function
If Control Output 1 and 2 are ON/OFF outputs (relay outputs, voltage outputs
for driving SSR, or SSR outputs), the number of times that a control output
turns ON and OFF can be counted. Based on the control output ON/OFF
count alarm set value, an alarm can be output and an error can be displayed if
the set count value is exceeded.
The default setting of the Control Output ON/OFF Alarm Set Value parameter
is 0. ON/OFF operations are not counted when this parameter is set to 0. To
enable counting ON/OFF operations, change the setting to a value other than
0.
Initial Setting Level
2. Select the Move to Advanced Function Setting Level parameter by press-
ing the M Key.
Advanced Function Setting Level
3. Press the D Key to enter the password (−169). It is possible to move to
the advanced function setting level by either pressing the M Key or wait-
ing two seconds without pressing any key.
4. Press the M Key to select the PF Setting parameter.
5. Press the U Key to select PFDP (Monitor/Setting Item).
6. Press the M Key to select the Monitor/Setting Item 1 parameter.
7. Press the U Key to select 7 (Alarm Value 1).
Initial Setting Level
8. Press the O Key for at least one second to move from the advanced
function setting level to the initial setting level.
Operation Level
9. Press the O Key for at least one second to move from the initial setting
level to the operation level.
Monitor/Setting Item Level
10. Press the PF Key to display Alarm Value 1 for the current bank.
amov
-169
Move to Ad-
vanced Function
Setting Level
init
off
Parameter
Initialization
pf
a-m
PF Setting
pf
pfdp
PF Setting
pfd1
1
Monitor/Setting
Item 1
pfd1
7
Monitor/Setting
Item 1
in-t
5
Input Type
C
25.0
100.0
al
m
▲
▲
al-1
0.0
Monitor/Setting
Item Display 1
C
