4
Names of Parts Section 1-1
OUT2 (Control Output 2)
Lights when the control output function assigned to control output 2 turns
ON. For a current output, however, OFF for a 0% output only.
With position-proportional models, OUT2 lights when the "close" output
turns ON.
4. STOP
Lights when operation is stopped.
During operation, this indicator lights when operation is stopped by an
event or by key input using the RUN/STOP function.
5. CMW (Communications Writing)
Lights when communications writing is enabled and is not lit when it is dis-
abled.
6. MANU (Manual Mode)
Lights when the auto/manual mode is set to manual mode.
7. (Key)
Lights when settings change protect is ON (i.e., when the U and D Keys
are disabled by protected status.
8. RSP
Lights when the SP Mode parameter is set to Remote SP Mode.
Temperature Unit The temperature unit is displayed when parameters are set to display a tem-
perature. The display is determined by the currently set value of the Tempera-
ture Unit parameter. c indicates °C and f indicates °F.
This indicator flashes during ST operation. It is OFF when an analog input is
set.
Ir Indicates whether infrared communications is enabled. Lights when communi-
cations is enabled. Not lit when infrared communications is disabled.
• Infrared Communications Light Receiver
Used when infrared cable is used.
1-1-3 Using the Keys
This section describes the basic functions of the front panel keys.
PF (Function (Auto/
Manual)) Key
(E5AN/EN-H Only)
This is a function key. When it is pressed for at least 1 second, the function set
in the PF Setting parameter will operate.
Example: When A-M (auto/manual) is selected in the PF Setting parameter
(initial value: A-M), the key operates as an auto/manual switch, switching
between Auto Mode and Manual Mode. If the key is pressed for more than 1
second (regardless of key release timing), the mode will switch.
O Key Press this key to move between setting levels. The setting level is selected in
the following order: operation level: adjustment level, initial setting level, com-
munications setting level.
M Key Press this key to change parameters within a setting level.
The parameters can be reversed by holding down the key (moving one per
second in reverse order).
U Key Each press of this key increments the value displayed on the No. 2 display or
advances the setting. Holding the key down speeds up the incrementation.
D Key Each press of this key decrements values displayed on the No. 2 display or
reverses the setting. Holding the key down speeds up the incrementation.
