Standards Compliance
5
5.3 UL Standards
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 201
Input/Output Terminals Power Supply Specifications
Analog output AO1, AO2, A0V Uses the LVLC power supply in the drive.
Pulse train output PO, A0V
Uses the LVLC power supply in the drive.
Use the UL Listed class 2 power supply for external power supply.
Pulse train input PI, A0V
Uses the LVLC power supply in the drive.
Use the UL Listed class 2 power supply for external power supply.
Safe disable input H1, H2, HC
Uses the LVLC power supply in the drive.
Use the UL Listed class 2 power supply for external power supply.
Serial communication input/output A+, B-, A0V
Uses the LVLC power supply in the drive.
Use the UL Listed class 2 power supply for external power supply.
24 V external power supply E24V, A0V Use the UL Listed class 2 power supply.
◆ Drive Motor Overload and Overheat Protection
The drive motor overload and overheat protection function complies with the National Electric Code (NEC) and
the Canadian Electric Code, Part I (CEC).
Set the Motor Rated Current and L1-01 [Motor Cool Type for OL1 Calc] through L1-04 [Motor oH FLT Reaction
Select] correctly to enable motor overload and overheat protection.
Refer to the control method and set the motor rated current with E2-01 [Mot Rated Current (FLA)], E5-03 [PM
Mot Rated Current (FLA)], or E9-06 [Motor Rated Current].
■ E2-01 Mot Rated Current (FLA)
No.
(Hex.)
Name Description
Default
(Range)
E2-01
(030E)
Mot Rated Current (FLA)
Sets the motor rated current in amps.
Determined by o2-04 and
C6-01
(10% to 200% of the drive
rated current)
Note:
• If E2-01 < E2-03 [Mot Rated Current (FLA) < Mot No-Load Current] the drive will detect oPE02 [Parameter Range Setting Error].
• The default settings and setting ranges are in these units:
–0.01 A: 4002 to 4023
–0.1 A: 4031 to 4675
The value set for E2-01 becomes the reference value for motor protection, the torque limit, and torque control.
Enter the motor rated current as written on the motor nameplate. The value of E2-01 is automatically set to the
value input for “Motor Rated Current” by the Auto-Tuning process.
■ E5-03 PM Mot Rated Current (FLA)
No.
(Hex.)
Name Description
Default
(Range)
E5-03
(032B)
PM Mot Rated Current
(FLA)
Sets the PM motor rated current (FLA).
Determined by E5-01
(10% to 200% of the drive
rated current)
Note:
When the drive model changes, the display units for this parameter also change.
• 0.01 A: 4002 to 4023
• 0.1 A: 4031 to 4675
The drive automatically sets E5-03 to the value input for “PM Motor Rated Current” after you do these types of
Auto-Tuning:
• PM Motor Parameter Settings
• PM Stationary Auto-Tuning
• PM StaTun for Stator Resistance
• PM Rotational Auto-Tuning
To Next Page
