Page #473 background imageLoading...
Page #473 background image
Parameter List
11
11.15 U: MONITORS
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 473
11.15 U: MONITORS
U1: STATUS
No.
(Hex.)
Name Description MFAO Signal Level Ref.
U1-01
(0040)
Frequency Reference Shows the actual frequency reference value. Parameter o1-03 [FrqDisplay Unit
Selection] selects the units.
Unit: 0.01 Hz
10 V = Max. frequency
(-10 V to +10 V)
-
U1-02
(0041)
Output Frequency Shows the actual output frequency. Parameter o1-03 [FrqDisplay Unit Selection] selects
the units.
Unit: 0.01 Hz
10 V = Max. frequency
(-10 V to +10 V)
-
U1-03
(0042)
Output Current Shows the actual output current.
The keypad shows the value of U1-03 in amperes (A). When looking at the monitor
through Modbus communications, the current is 8192 = drive rated current (A).
Calculate the current from the monitor value that is in at Modbus communications using
Numerals being displayed / 8192 × drive rated current (A).
Unit: Determined by the drive model.
0.01 A:4002 to 4023
0.1 A: 4031 to 4675
10 V = Drive rated
current
-
U1-04
(0043)
Control Method Shows the drive control method.
0 : V/f Control
1 : PG V/f Control
2 : OLVector
3 : CLVector
4 : Adv OLVector
5 : PM OLVector
6 : PM AOLVector
7 : PM CLVector
8 : EZ Vector
No signal output
available
-
U1-05
(0044)
Motor Speed Shows the actual detected motor speed. Parameter o1-03 [FrqDisplay Unit Selection]
selects the units.
Unit: 0.01 Hz
10 V = Max. frequency
(-10 V to +10 V)
-
U1-06
(0045)
Output Voltage Ref Shows the output voltage reference.
Unit: 0.1 V
400 V class: 10 V = 400
Vrms
-
U1-07
(0046)
DC Bus Voltage Shows the DC bus voltage.
Unit: 1 V
400 V class: 10 V = 400
V
-
U1-08
(0047)
Output Power Shows the internally-calculated output power.
Changing the setting of A1-02 [Control Method] also changes the signal level of the
analog output.
A1-02 = 0, 1 [V/f Control]: Drive capacity (kW)
A1-02 = 2 to 8 [Vector Control]: Motor Rated Power (kW) [E2-11]
Unit: Drive capacity and C6-01 [ND/HD Duty Selection] calculate the maximum
applicable motor output.
Less than 11 kW (15 HP): 0.01 kW
Less than 11 kW (15 HP): 0.1 kW
10 V: Drive capacity
(motor rated power) kW
(-10 V to +10 V)
-
U1-09
(0048)
Torque Reference Shows the internal torque reference value.
Unit: 0.1%
10 V = Motor rated
torque (-10 V to +10 V)
-
U1-10
(0049)
In Terminal Status Shows the status of the MFDI terminal where 1 = (ON) and 0 = (OFF).
For example, U1-10 shows 00000011 when terminals DI1 and DI2 are ON.
bit 0 : Terminal DI1 (MFDI 1)
bit 1 : Terminal DI2 (MFDI 2)
bit 2 : Terminal DI3 (MFDI 3)
bit 3 : Terminal DI4 (MFDI 4)
bit 4 : Terminal DI5 (MFDI 5)
bit 5 : Terminal DI6 (MFDI 6)
bit 6 : Terminal DI7 (MFDI 7)
bit 7 : Terminal DI8 (MFDI 8)
No signal output
available
-
U1-11
(004A)
Out Terminal Status Shows the status of the MFDO terminal where 1 = (ON) and 0 = (OFF).
For example, U1-11 shows 00000011 when terminals 2NO-2CM and 3NO-3CM are
ON.
bit 0 : Terminals 2NO-2CM
bit 1 : Terminals 3NO-3CM
bit 2 : Terminals 4NO-4CM
bit 3 : Not used (normal value of 0).
bit 4 : Not used (normal value of 0).
bit 5 : Not used (normal value of 0).
bit 6 : Not used (normal value of 0).
bit 7 : Fault relay 1NO/1NC-1CM
No signal output
available
-
