2.9 Installation Methods
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 59
2.9 Installation Methods
The drive installation methods include standard installation and external heatsink installation.
◆ Standard Installation
Refer to Drive Exterior and Mounting Dimensions on page 367 for more information about external dimensions
and installation procedure.
◆ External Heatsink
An attachment is necessary to install drive models smaller than 4060 (400 V class) with the heatsink outside of the
panel.
Note:
• The exterior mounting dimensions and installation dimensions for a standard installation are different than the dimensions for an
external heatsink installation.
• The shaded parts of the panel cut-out dimensions are the gasket dimensions. Make sure that the gasket is not smaller than the specified
dimension.
