10.4 Drive Derating
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 361
Model
Rated Current (A)
Heavy Duty Rating (HD2) Normal Duty Rating (ND2)
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz
4009
8.6 7.9 6.9 6.2 5.4 4.6 7.6 7.0 6.1 5.5 4.8 4.1
4012
9.8 8.9 7.6 6.7 5.6 4.5 11.0 10.0 8.5 7.5 6.2 5.0
4018
14.1 12.9 11.0 9.7 8.2 6.6 15.2 13.9 11.8 10.5 8.8 7.1
4023
18.0 16.4 14.0 12.4 10.4 8.4 21 19.3 16.4 14.6 12.2 9.9
4031
27.2 24.7 21.0 18.5 15.4 12.4 27 24.5 20.9 18.4 15.4 12.3
4038
34.7 31.6 27.0 23.9 20.1 16.2 34 32.5 27.7 24.6 20.6 16.6
4044
34.0 34.0 34.0 30.1 25.3 20.4 40 39.6 34.1 30.5 25.9 21.3
4060
40.0 40.0 40.0 34.8 28.3 21.7 52 46.9 39.2 34.1 27.7 21
4075
52.0 52.0 52.0 46.1 38.6 31.2 65 64.1 54.6 48.3 40.4 33
4089
65.0 65.0 65.0 57.6 48.3 39.0 77 76.6 65.5 58.0 48.7 39
4103
77.0 77.0 77.0 68.2 57.2 46.2 96 96.0 84.1 74.6 62.8 51
4140
96.0 96.0 78.7 67.2 - - 124 108.7 85.7 70 - -
4168
124.0 124.0 101.7 86.8 - - 156 139.8 115.5 99 - -
4208
156.0 156.0 127.9 109.2 - - 180 155.5 118.7 94 - -
4250
180.0 180.0 147.6 126.0 - - 240 212.9 172.3 145 - -
4296
240.0 240.0 196.8 168.0 - - 302 268.8 218.9 186 - -
4371
302.0 302.0 247.6 211.4 - - 361 318.5 254.7 212 - -
4389
361.0 361.0 296.0 252.7 - - 414 370 303.3 259 - -
4453
414.0 345.0 - - - - 477 367 - - - -
4568
477.0 397.5 - - - - 515 397 - - - -
4675
- - - - - - - - - - - -
◆ Carrier Frequency Settings and Rated Current Values when Using PM
Advanced Open Loop Vector Control Method
The following tables show how the drive rated output current changes when C1-02 [Decel Time 1] value changes,
and when A1-02 = 6 [Control Method = PM AOLVector]. The output current value changes linearly as the carrier
frequency changes. You can use the values from the tables to calculate a frequency that is not shown.
■ 400 V Class
Table 10.12 AOLV/PM Carrier Frequency and Rated Current Derating (< 460 V)
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
4002
1.8 1.8 1.7 1.3 1.0 0.6 2.1 1.9 1.7 1.6 1.4 1.2
4004
3.4 3.4 3.2 2.4 1.7 1.0 4.1 3.7 3.3 2.8 2.4 2.0
4005
4.8 4.8 4.5 3.8 3.0 2.3 5.4 5.0 4.7 4.3 3.9 3.6
4007
5.5 5.5 5.2 4.2 3.2 2.3 7.1 6.1 5.2 4.2 3.2 2.3
4009
7.2 7.2 6.9 5.8 4.8 3.8 8.9 7.9 6.8 5.8 4.8 3.7
4012
9.2 9.2 8.7 7.0 5.4 3.8 11.9 10.3 8.6 7.0 5.4 3.8
4018
14.8 14.8 14.0 11.4 8.9 6.3 17.5 16.5 14.0 11.4 8.9 6.3
4023
18.0 18.0 17.0 13.9 10.8 7.7 23.4 20.4 17.3 14.1 11.0 7.8
4031
24.0 24.0 22.6 18.4 14.1 9.9 31.0 26.8 22.6 18.3 14.1 9.9
4038
31.0 31.0 29.2 23.9 18.6 13.3 38.0 34.5 29.2 23.9 18.6 13.3
4044
39.0 39.0 36.8 30.1 23.4 16.7 44.0 41.6 35.5 29.5 23.4 17.3
4060
45.0 45.0 42.1 33.3 24.4 15.6 59.6 50.8 42.0 33.2 24.4 15.6
