Parameter List
11
11.8 H: TERMINALS
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 443
Setting Function Description Ref.
D GenerTrqLim
Enters the torque limit that is the same for all quadrants for forward, reverse, and regenerative operation if the
motor rated torque is 100%.
720
E OvUntrq Level
Enters a signal to adjust the overtorque/undertorque detection level.
Note:
Use this function with L6-01 [Trq Det1 Select]. This parameter functions as an alternative to L6-02 [Trq Det1
Level].
720
F PID Fbk
Enters the PID feedback value.
721
10 PID SetPoint
Enters the PID setpoint.
721
11 Diff PIDFbk
Enters the PID differential feedback value if the full scale analog signal (10 Vor 20 mA) is 100%.
721
12 AcDcTimeGain
Enters a signal to adjust the gain used for C1-01 to C1-08 [Accel Time 1 to Decel Time 4] if the full scale analog
signal (10 Vor 20 mA) is 100%.
721
13 DCInjBrakCurr
Enters a signal to adjust the current level used for DC Injection Braking if the drive rated output current is 100%.
721
14 StallPLev@Rn
Enters a signal to adjust the stall prevention level during run if the drive rated current is 100%.
722
15 OutFLowLimSel
Enters a signal to adjust the output frequency lower limit level if E1-04 [Max Output Frequency] = 100%.
722
16 Mot PTC Input
Uses the motor Positive Temperature Coefficient (PTC) thermistor to prevent heat damage to the motor if the
current value when the 10 V (or 20 mA) analog signal is input is 100%.
722
30 Q2pack AI1
Use with Q2pack. Refer to the Q2pack online manual for more information.
722
31 Q2pack AI1
Use with Q2pack. Refer to the Q2pack online manual for more information.
722
32 Q2pack AI3
Use with Q2pack. Refer to the Q2pack online manual for more information.
723
◆ H4: ANALOG OUTPUTS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H4-01
(041D)
AO1 An.Out Select
Sets the monitor number to send from MFAO terminal AO1.
Set the x-xx part of the U: MONITORS. For example, set H4-01 = 102 to monitor U1-02
[Output Frequency].
102
(000 - 999)
724
H4-02
(041E)
RUN
AO1 An.Out Gain
Sets the gain of the monitor signal that is sent from MFAO terminal AO1.
Sets the analog signal output level from the terminal AO1 at 10 Vor 20 mA as 100%
when an output for monitoring items is 100%.
100.0%
(-999.9 - +999.9%)
724
H4-03
(041F)
RUN
AO1 An.Out Bias
Sets the bias of the monitor signal that is sent from MFAO terminal AO1.
Set the level of the analog signal sent from terminal AO1 at 10 Vor 20 mA as 100%
when an output for monitoring items is 0%.
0.0%
(-999.9 - +999.9%)
725
H4-04
(0420)
AO2 An.Out Select
Sets the monitoring number to be output from the MFAO terminal AO2.
Set the x-xx part of the U: MONITORS. For example, set H4-04 to 102 to monitor U1-
02 [Output Frequency].
103
(000 - 999)
725
H4-05
(0421)
RUN
AO2 An.Out Gain
Sets the gain of the monitor signal that is sent from MFAO terminal AO2.
When an output for monitoring items is 0%, this parameter sets the analog signal output
level from the AO2 terminal at 10 Vor 20 mA as 100%.
50.0%
(-999.9 - +999.9%)
725
H4-06
(0422)
RUN
AO2 An.Out Bias
Sets the bias of the monitor signal that is sent from MFAO terminal AO2.
Set the level of the analog signal sent from the AO2 terminal at 10 Vor 20 mA as 100%
when an output for monitoring items is 0%.
0.0%
(-999.9 - +999.9%)
725
