12.10 o: KEYPAD
810 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
■ o1-51 Trend Plot Time Scale Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-51
(11CB)
RUN
Trend Plot Time Scale
Setting
Sets the time scale (horizontal axis) to display the trend plot. When you change this setting, the
drive automatically adjusts the data sampling time. This parameter is only available with an LCD
keypad.
5 s
(1 - 3600 s)
■ o1-55 AnGauge Area Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-55
(11EE)
RUN
AnGauge Area Selection
Sets the range used to display the monitor set in o1-24 [Cust.Monitor 1] as an analog gauge. This
parameter is only available with an LCD keypad.
1
(0, 1)
0 : + - Area (- o1-56 - o1-56 )
1 : + Area (0 - o1-56 )
■ o1-56 AnGauge Area Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-56
(11EF)
RUN
AnGauge Area Setting
Sets the value used to display the monitor set in o1-24 [Cust.Monitor 1] as an analog meter. This
parameter is only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
◆ o2: KEYPAD OPERATION
■ o2-01 LO/RE Key Selection of Function
No.
(Hex.)
Name Description
Default
(Range)
o2-01
(0505)
LO/RE Key Selection of
Function
Sets the function that lets the drive switch between LOCAL and REMOTE Modes using the
button.
1
(0, 1)
0 : Disabled
You cannot use to switch between LOCAL and REMOTE Modes.
1 : Enabled
You can use to switch between LOCAL and REMOTE Modes when the drive is stopped. When LOCAL
Mode is selected, on the keypad will come on.
WARNING! Sudden Movement Hazard. The drive may start unexpectedly if switching control sources when setting b1-07 = 2
[LO/RE Run Selection = Accept RUN]. Clear all personnel from rotating machinery and electrical connections prior to switching
control sources. Failure to comply may cause death or serious injury.
WARNING! Sudden Movement Hazard. Fully examine all mechanical and electrical connections before you change o2-01 [LO/
RE Key Selection of Function] or b1-07 [LO/RE Run Selection]. If b1-07 = 2 [Accept RUN] and there is an active Run command
when you switch from LOCAL to REMOTE Mode, the drive can start suddenly. Failure to obey can cause serious injury or
death.
Table 12.58 Function Settings via o2-01 through b1-07
Function Selection
LOCAL/REMOTE Run Selection
Switching from LOCAL Mode to
REMOTE Mode
Switching from REMOTE Mode to
LOCAL Mode
o2-01 = 0 [Disabled] b1-07 = 1 [Cycle RUN] The drive will not switch modes. The drive will not switch modes.
b1-07 = 2 [Accept RUN]
o2-01 = 1 [Enabled] b1-07 = 1 [Cycle RUN] The drive will not start operating although
the Run command is active. When you set
Run command to active again, the drive
will start to run.
The drive cannot operate because the Run
command is not enabled.
b1-07 = 2 [Accept RUN] When the Run command is active, the
drive will start to run immediately when
the mode switches from LOCAL to
REMOTE.
The drive cannot operate because the Run
command is not enabled.
