Parameter List
11
11.7 F: OPTIONS
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 427
◆ F7: ETHERNET
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F7-01
(03E5)
IP Address 1
Sets the first octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
• Use parameters F7-01 to F7-04 [IPAddress 1 to IPAddress 4] to set the IP
Address. Be sure to set a different IP address for each drive on the network.
• Also set parameters F7-01 to F7-12.
192
(0 - 255)
658
F7-02
(03E6)
IP Address 2
Sets the second octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
• Use parameters F7-01 to F7-04 [IPAddress 1 to IPAddress 4] to set the IP
Address. Be sure to set a different IP address for each drive on the network.
• Also set parameters F7-01 to F7-12.
168
(0 - 255)
658
F7-03
(03E7)
IP Address 3
Sets the third octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
• Use parameters F7-01 to F7-04 [IPAddress 1 to IPAddress 4] to set the IP
Address. Be sure to set a different IP address for each drive on the network.
• Also set parameters F7-01 to F7-12.
1
(0 - 255)
659
F7-04
(03E8)
IP Address 4
Sets the fourth octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
• Use parameters F7-01 to F7-04 [IPAddress 1 to IPAddress 4] to set the IP
Address. Be sure to set a different IP address for each drive on the network.
• Also set parameters F7-01 to F7-12.
20
(0 - 255)
659
F7-05
(03E9)
Subnet Mask 1
Sets the first octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
255
(0 - 255)
659
F7-06
(03EA)
Subnet Mask 2
Sets the second octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
255
(0 - 255)
659
F7-07
(03EB)
Subnet Mask 3
Sets the third octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
255
(0 - 255)
659
F7-08
(03EC)
Subnet Mask 4
Sets the fourth octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
0
(0 - 255)
659
F7-09
(03ED)
Gateway Addr 1
Sets the first octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
192
(0 - 255)
660
F7-10
(03EE)
Gateway Addr 2
Sets the second octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
168
(0 - 255)
660
F7-11
(03EF)
Gateway Addr 3
Sets the third octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
1
(0 - 255)
660
F7-12
(03F0)
Gateway Addr 4
Sets the fourth octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
1
(0 - 255)
660
