2 Models and External Dimensions
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
2-3 Model Tables
2
2-3-7 External Regeneration Resistor and External Regeneration Resistance Unit Model Tables
The following tables list the models of External Regeneration Resistors and External Regeneration
Resistance Units.
2-3-7 External Regeneration Resistor and External Regeneration
Resistance Unit Model Tables
External Regeneration Resistors
Applicable Servo Drive Model Specifications
R88D-1SN01L-ECT/ -1SN02L-ECT R88A-RR12015 Regeneration process
capacity: 24 W, 15 Ω
R88D-1SN01H-ECT/ -1SN02H-ECT R88A-RR12025 Regeneration process
capacity: 24 W, 25 Ω
R88D-1SN150H-ECT R88A-RR30002R5 Regeneration process
capacity: 60 W, 2.5 Ω
R88D-1SN75H-ECT R88A-RR30004 Regeneration process
capacity: 60 W, 4 Ω
R88D-1SN55H-ECT R88A-RR30005R4 Regeneration process
capacity: 60 W, 5.4 Ω
R88D-1SN20H-ECT/ -1SN30H-ECT/ -1SN150F-ECT R88A-RR30010 Regeneration process
capacity: 60 W, 10 Ω
R88D-1SN01L-ECT/ -1SN02L-ECT R88A-RR30015 Regeneration process
capacity: 60 W, 15 Ω
R88D-1SN55F-ECT/ -1SN75F-ECT R88A-RR30016 Regeneration process
capacity: 60 W, 16 Ω
R88D-1SN15H-ECT R88A-RR30017 Regeneration process
capacity: 60 W, 17 Ω
R88D-1SN04L-ECT/ -1SN08H-ECT/ -1SN10H-ECT/
-1SN20F-ECT
*1
/ -1SN30F-ECT
*1
*1. Use two series-connected External Regeneration Resistors for this model.
R88A-RR30020 Regeneration process
capacity: 60 W, 20 Ω
R88D-1SN01H-ECT/ -1SN02H-ECT/
-1SN04H-ECT
R88A-RR30025 Regeneration process
capacity: 60 W, 25 Ω
R88D-1SN06F-ECT
*1
/ -1SN10F-ECT
*1
/
-1SN15F-ECT
*1
R88A-RR30033 Regeneration process
capacity: 60 W, 33 Ω
External Regeneration Resistance Units
Applicable Servo Drive Model Specifications
R88D-1SN150H-ECT R88A-RR55002R5 Regeneration process
capacity: 110 W, 2.5 Ω
R88D-1SN75H-ECT R88A-RR55004 Regeneration process
capacity: 110 W, 4 Ω
R88D-1SN55H-ECT R88A-RR55005R4 Regeneration process
capacity: 110 W, 5.4 Ω
R88D-1SN150F-ECT R88A-RR55010 Regeneration process
capacity: 110 W, 10 Ω
R88D-1SN55F-ECT/ -1SN75F-ECT R88A-RR55016 Regeneration process
capacity: 110 W, 16 Ω
R88D-1SN150H-ECT R88A-RR1K602R5 Regeneration process
capacity: 640 W, 2.5 Ω
