Items to Check After Unpacking
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
Items to Check After Unpacking
After you unpack the product, check the following items.
• Is this the model you ordered?
• Was there any damage sustained during shipment?
The model, rating and lot number of the 1S-series Servo Drive are given on the product nameplate.
The notifications and their meanings of lot number and serial number are explained below.
• Capacity 3 kW or less:
Notation: Lot No. DDMYY xxxx
DDMYY: Lot number, : For use by OMRON, xxxx: Serial number
“M” gives the month (1 to 9: January to September, X: October, Y: November, Z: December)
• Capacity 5.5 kW or more:
Notation: Lot No. MMYYDD xxx
MMYYDD: Lot number, : For use by OMRON, xxx: Serial number
This product comes with the following accessories.
• INSTRUCTION MANUAL × 1 copy
• Warning label × 1 sheet
• General Compliance Information and instructions for EU × 1 copy
• Attached connectors (Depends on the model. Refer to the following table.)
When UL/CSA certification is required, attach the warning label to a place around the Servo Drive.
Servo Drive
Nameplate of Servo Drive
Accessories of Servo Drive
RUN
ERR
IN
L/A
R88D-1SN
L/A
FS
OUT
Ether
CAT
Nameplate display location
Name plate example: 100 VAC 100 W Servo Drive
Servo Drive model
Servo Drive rating
Lot number and serial number
