3 - 133
3 Specifications
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
3-7 Reactor Specifications
3
3-7-1 General Specifications
3-7 Reactor Specifications
Connect a Reactor to the Servo Drive for reduction of harmonic current. Select an appropriate Reactor
according to the Servo Drive model.
Refer to 2-4-8 Reactor Dimensions on page 2-121 for dimensions.
3-7-1 General Specifications
Item
Model
R88A-PD20/200 VAC R88A-PD40/400 VAC
Insulation class Class H
Dielectric strength Between terminals and case: 4,000 VAC for 1 min (at 50/60 Hz)
Insulation resistance Between terminals and case: 100 MΩ min. (at 1,000 VDC)
Operating ambient tem-
perature and humidity
0 to 55°C, 90% max. (with no condensation)
Storage ambient tempera-
ture and humidity
-20 to 65°C, 90% max. (with no condensation)
Operating and storage
atmosphere
No corrosive gases
3-7-2 Characteristics
Applicable Servo Drive DC Reactor
Wire size
*1
Voltage Model Model
Rated
current
Inductance
(0% to 20%)
Weight
100 VAC R88D-
1SN01L-ECT
R88A-
PD2002
1.6 A 21.4 mH 1.8 kg AWG 18 to 14,
0.75 to 2.0 mm
2
R88D-
1SN02L-ECT
R88A-
PD2004
3.2 A 10.7 mH 1.9 kg
R88D-
1SN04L-ECT
R88A-
PD2007
6.1 A 6.75 mH 2.0 kg AWG 14,
1.5 to 2.0 mm
2
200 VAC R88D-
1SN01H-ECT
R88A-
PD2002
1.6 A 21.4 mH 1.8 kg AWG 18 to 14,
0.75 to 2.0 mm
2
R88D-
1SN02H-ECT
R88D-
1SN04H-ECT
R88A-
PD2004
3.2 A 10.7 mH 1.9 kg AWG 16 to 14,
1.3 to 2.0 mm
2
R88D-
1SN08H-ECT
R88A-
PD2007
6.1 A 6.75 mH 2.0 kg
R88D-
1SN10H-ECT
R88A-
PD2015
9.3 A 3.51 mH 2.0 kg
R88D-
1SN15H-ECT
AWG 12 to 10,
3.3 to 5.5 mm
2
R88D-
1SN20H-ECT
R88A-
PD2022
13.8 A 2.51 mH 2.9 kg
R88D-
1SN30H-ECT
R88A-
PD2037
22.3 A 1.6 mH 4.4 kg AWG 10,
4.0 to 5.5 mm
2
