7 Applied Functions
7 - 24
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
To control the brake forcibly via EtherCAT communications, set Digital outputs - Physical outputs
(60FE-01 hex) and Function Output - Bit Mask (4602-01 hex). However, to prevent a workpiece from
falling for a vertical axis, the brake is constantly applied except when the status of ESM is Operational.
Relationship between Brake Interlock Function and Status of ESM
Set External Brake Interlock Output - Port Selection (4663-01 hex) to change the output port of
the brake interlock signal.
The following table lists output ports corresponding to values of Port Selection.
You can monitor the output status of the brake interlock signal by I/O Monitor - Physical I/O
(4600-81 hex), Digital inputs (60FD-00 hex) bit 26, and External Brake Interlock Output - Signal
Status (4663-81 hex).
The output status is given to data that are indicated with a check mark in the following table.
7-6-2 Description of Operation
Status of ESM
Physical outputs
(60FE-01 hex)
Bit Mask
(4602-01 hex)
Brake state
Digital inputs
bit 26
bit 0
bit 28
*1
*1. This bit is available for the unit version 1.4 or later.
bit 0
bit 28
*1
Operational 0 --- 0 0 Held 0
1 Released 1
1 0 Held 0
1Held0
--- 0 0 0 Held 0
1Held 0
1 0 Held 0
1 Released 1
Other than Opera-
tional
0 --- 0 --- Held 0
1
Held
*2
*2. Released if the unit version is 1.1 or earlier.
0
*3
*3. 1 if the unit version is 1.1 or earlier.
1 0 Held 0
1Held0
Value of Port Selection Output port
0 Brake output (BKIR)
1 General Output 1 (OUT1)
2 General Output 2 (OUT2)
4 General Output 3 (OUT3)
Output port
Physical I/O
Digital inputs
bit 26
Signal Status
(4663-81 hex)
bit 17 bit 18 bit 19 bit 30
General Output 1
(OUT1)
√
--- --- ---
√√
General Output 2
(OUT2)
---
√
--- ---
√√
General Output 3
(OUT3)
--- ---
√
---
√√
Brake output (BKIR)
--- --- ---
√√
---
