9 - 97
9 Details on Servo Parameters
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
9-10 Display-related Objects
9
9-10 Display-related Objects
These objects are used for the display setting.
• Selects data to be displayed on the 7-segment display on the front panel.
 Description of Set Values
Index
(hex)
Sub-
index
(hex)
Object name
Setting
range
Unit
Default
setting
Data
attri-
bute
Size Access
PDO
map
Complete
access
Modes of
operation
4210 --- Display --- --- --- --- --- --- --- Possible ---
00 Number of
entries
--- --- 01 hex --- 1 byte
(U8)
RO --- --- ---
01 LED Display
Selection
0 to 1 --- 0 A 4 bytes
(INT32)
RW --- --- ---
Subindex 81 hex: LED Display Selection
Set value Description
0 PDS state (simple)
1 EtherCAT node address
