Page #393 background imageLoading...
Page #393 background image
15. Wi-Fi/Bluetooth
393
Camera Power Operations
Even when the camera is turned off, the smartphone can be used to start
the camera and record images, or check the recorded images.
Getting started:
1
Connect to a smartphone using Bluetooth. (l 374)
2
Enable [Remote Wakeup] on the camera.
0
¨ [ ] ¨ [ ] ¨ [Bluetooth] ¨ [Remote Wakeup] ¨ [ON]
3
Set the camera on/off switch to [OFF].
4
On the smartphone, start up “LUMIX Sync”.
Turning On the Camera
Select [Remote shooting] in the “LUMIX Sync” home screen.
0
(iOS devices) When a message to confirm the change of destination is displayed,
select [Join].
0 The camera turns on, and automatically connects using Wi-Fi.
Turning Off the Camera
1
Select [ ] in the “LUMIX Sync” home screen.
2
Select [Turn off the camera].
3
Select [Power OFF].
0 When [Remote Wakeup] has been set, the Bluetooth function continues to
work even if the camera on/off switch is set to [OFF], so the battery will drain.
Wi-FiBluetooth
