Parker AC10 series User Manual

1-2 Introduction
AC10 Inverter
1.3 Product Range
Supply Part Number kW
Input
current
(A)
Output
Current
(A)
Input
protection
current
Estimated
efficiency
Inductance of
output choke
(mH)
1Ph 230V
16G-11-0025-BF 0.4 6.1 2.5 10.0 ≥95 1.4
16G-11-0045-BF
0.75 11.4 4.5 18.1 ≥96 1.4
16G-11-0070-BF
1.5 16.8 7 25.2 ≥93 1.0
16G-11-0100-BF
2.2 21.0 10 32.0 ≥96 0.7
3Ph 230V
16G-31-0025-BF
0.4 4.3 2.5
8.2 ≥95
1.4
16G-31-0045-BF
0.75 7.6 4.5
11.5 ≥95 1.4
16G-31-0070-BF
1.5 12.0 7
18.2 ≥96 1.0
16G-31-0100-BF
2.2 14.3 10
21.5 ≥96 0.7
3Ph 400V
16G-41-0020-BF
0.75 4.1 2 6.5 ≥95 1.4
16G-41-0040-BF
1.5 6.9 4 11.0 ≥96 1.4
16G-41-0065-BF
2.2 9.6 6.5 15.0 ≥96 1.0
16G-41-0080-BF
3.7 11.6 8 18.0 ≥96 1.0
16G-41-0090-BF
4.0 13.6 9 21.0 ≥96 0.7
16G-42-0120-BF
5.5 18.8 12 29.0 ≥96 0.47
16G-42-0170-BF
7.5 22.1 17 34.0 ≥96 0.35
16G-43-0230-BF
11 30.9 23 46.5 ≥97 0.23
16G-43-0320-BF
15 52 32 80.0 ≥97 0.18
